OpenWrt 24.10.1 - Service Release

bartje · April 18, 2025, 11:27am

Hello,
Thank you for the link,
But i'm not sure it applies here.
the link mentions the update from 23.05 to 24.10
I am already on 24.10.0 and can't update to 24.10.01

Also I can't find how to check if this is needed and I remember having go trough this on the initial install (v23.05)

this ofcourse could be the reason.

But my feeling is the ASU for some reason(maybe cache) includes the wrong openWRT version for "mediatek/filogic" systems.
If I know how to open an itb file inwindows I might be able to check this.

Plutus · April 18, 2025, 11:36am

Dlink dir-3040 a1 upgrade via owut from 24.10 to 24.10.1 went smooth this time. Thanks

mattimat · April 18, 2025, 12:30pm

Xiaomi ax9000 and xiaomi ax3000T upgraded with firmware selector generated images. Plain vanilla only 802.11s meshes. Upgrade over mesh.

systemcrash · April 18, 2025, 1:41pm

MT6000 / 24.10.0 -> 24.10.1 asu

all OK.

I still get

daemon.notice netifd: radio0 (3365): WARNING: Variable 'data' does not exist or is not an array/object
daemon.notice netifd: radio1 (3375): WARNING: Variable 'data' does not exist or is not an array/object

Does something need removing from /etc/config/wireless?

config wifi-device 'radio0'
	option type 'mac80211'
	option path 'platform/soc/18000000.wifi'
	option channel '6'
	option band '2g'
	option htmode 'HT20'
	option cell_density '0'

config wifi-device 'radio1'
	option type 'mac80211'
	option path 'platform/soc/18000000.wifi+1'
	option channel '36'
	option band '5g'
	option htmode 'HE80'
	option cell_density '0'

Also get the following during early boot, probably because some addresses aren't available yet, but everything works out fine when procd retries.

daemon.err uhttpd[2849]: bind(): Address not available
daemon.err uhttpd[2849]: bind(): Address not available
daemon.err uhttpd[2849]: Error: No sockets bound, unable to continue

gbentz2 · April 18, 2025, 1:41pm

were you able to recover?

systemcrash · April 18, 2025, 1:46pm

You're welcome to update the wiki yourself (recent device) or ask @Linaro :

github.com/openwrt/openwrt

mediatek/filogic: add Keenetic KN-3811 support

committed 06:52PM - 08 Dec 24 UTC

Linaro1985

+390 -0

Specification: * Mediatek MT7981BA * 256 MB SPI-NAND * 512 MB DDR4 RAM * MT7…976CN DBDC AX Wi-Fi * MediaTek MT7531AE (3x LAN Gigabit ports) + Internal Gbe Phy (1x WAN Gigabit port) * 4x LED (power, internet, fn, wifi) * 3x buttons (wps, fn, reset) * 1x USB 3.0 port Serial Interface: * 3 Pins GND, RX, TX * Settings: 115200, 8N1 Notes: * The device supports dual boot mode * Fn led reassigned to wlan 2.4 Flash instruction: The only way to flash OpenWrt image is to use tftp recovery mode in U-Boot: 1. Configure PC with static IP 192.168.1.2/24 and tftp server. 2. Rename "openwrt-mediatek-filogic-keenetic_kn-3811-squashfs-factory.bin" to "KN-3811_recovery.bin" and place it in tftp server directory. 3. Connect PC with ethernet port, press the reset button, power up the device and keep button pressed until status led start blinking. 4. Device will download file from server, write it to flash and reboot. Signed-off-by: Maxim Anisimov <maxim.anisimov.ua@gmail.com> Link: https://github.com/openwrt/openwrt/pull/17135 Signed-off-by: Hauke Mehrtens <hauke@hauke-m.de>

nickyng · April 18, 2025, 1:59pm

yes, i can recover the mx4200 v1 to the previous working 24.10.0 as this router has dual firmware flashing backup ...

gbentz2 · April 18, 2025, 2:48pm

okay cool! Yea I think my mx5300 has dual firmware but for the life of me could not figure it out

actually it doesn't lol

nagual · April 18, 2025, 4:10pm

Hello
Raspberry Pi 3 Model B Rev 1.2
ARMv8 Processor rev 4
OpenWrt 24.10.1 (r28597-0425664679)

Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.137655] ------------[ cut here ]------------
Fri Apr 18 15:55:10 2025 kern.err kernel: [    0.138484] Device 'grafx' does not have a release() function, it is broken and must be fixed. See Documentation/core-api/kobject.rst.
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.140213] WARNING: CPU: 0 PID: 1 at drivers/base/core.c:2516 0xffffffc0804c31a4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.141910] Modules linked in:
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.142736] CPU: 0 PID: 1 Comm: swapper/0 Not tainted 6.6.86 #0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.143574] Hardware name: Raspberry Pi 3 Model B Rev 1.2 (DT)
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.144402] pstate: 60400005 (nZCv daif +PAN -UAO -TCO -DIT -SSBS BTYPE=--)
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.145249] pc : 0xffffffc0804c31a4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.146069] lr : 0xffffffc0804c31a4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.146843] sp : ffffffc080c1b6d0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.147594] x29: ffffffc080c1b6d0 x28: 0000000000000000 x27: ffffff8001a42810
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.148374] x26: ffffff80019804b8 x25: ffffff80019804a0 x24: ffffffc0808d76e8
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.149138] x23: ffffffc08096e550 x22: 0000000000000000 x21: ffffffc08096ee58
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.149884] x20: 0000000000000000 x19: ffffff80019800b8 x18: 0000000000000075
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.150618] x17: 0000000000000000 x16: 0000000000000000 x15: ffffffc080a9e318
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.151323] x14: 000000000000015f x13: 0000000000000075 x12: 00000000ffffffea
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.152003] x11: 00000000ffffefff x10: ffffffc080af6318 x9 : ffffffc080a9e2c0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.152673] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.153360] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc080c1b4d0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.154047] x2 : ffffffc080a9e258 x1 : ffffffc080a9e258 x0 : 000000000000007a
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.154733] Call trace:
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.155377]  0xffffffc0804c31a4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.155996]  0xffffffc08085d3f0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.156576]  0xffffffc0804c338c
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.157147]  0xffffffc0804e89e4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.157692]  0xffffffc0804e8ae8
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.158211]  0xffffffc080470f38
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.158697]  0xffffffc0804ceebc
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.159152]  0xffffffc0804cc268
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.159607]  0xffffffc0804cc448
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.160054]  0xffffffc0804cc538
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.160477]  0xffffffc0804cc68c
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.160879]  0xffffffc0804ca108
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.161260]  0xffffffc0804cca2c
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.161617]  0xffffffc0804cccf4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.161953]  0xffffffc0804cb0ac
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.162274]  0xffffffc0804c8700
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.162573]  0xffffffc0804cea20
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.162846]  0xffffffc0804feb58
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.163100]  0xffffffc0804fef40
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.163323]  0xffffffc0804fe654
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.163514]  0xffffffc0804ceebc
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.163695]  0xffffffc0804cc268
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.163877]  0xffffffc0804cc448
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164058]  0xffffffc0804cc538
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164236]  0xffffffc0804cc75c
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164414]  0xffffffc0804ca058
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164591]  0xffffffc0804cbac4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164767]  0xffffffc0804cb2a0
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.164942]  0xffffffc0804cd6c4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.165119]  0xffffffc0804ceb80
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.165296]  0xffffffc080a378a4
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.165475]  0xffffffc080012c28
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.165655]  0xffffffc080a1100c
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.165837]  0xffffffc08087c728
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.166020]  0xffffffc080013a50
Fri Apr 18 15:55:10 2025 kern.warn kernel: [    0.166204] ---[ end trace 0000000000000000 ]---

ne20002 · April 18, 2025, 6:38pm

I upgraded from 24.10.0 to 24.10.1 via attended sysupgrade my BPI-R3 without issue.

bosukes · April 18, 2025, 11:23pm

It's just a new device, I don't know how. That's why I ask.

bosukes · April 18, 2025, 11:24pm

Any news about availability of Wi-Fi 7 routers? I'd be happy to be a beta tester, would buy any device within 150$ range and would try it.

mil4898 · April 19, 2025, 8:14am

Hello Guys,

Trying to build an image now , build system seems to be hanging , no progress for hours .

lleachii · April 19, 2025, 8:22am

There's already reports, see the Firmware Selector thread starting here:

rmappleby · April 19, 2025, 9:06am

When I moved to 14.10.0, I had problems upgrading a remotely managed router because the device name assigned to the RNDIS cellular modem by kmod-usb-net-rndis changed from "usb0" to "eth0", which broke the network configuration that sysupgrade had retained across the reflash, and meant that the router was left running the successfully upgraded firmware, but completely offline. It required a days driving to resolve that.

So I note with... interest? frustration? excitement? panic? ...that under the announcement of 24.10.1 in the "Various fixes and improvements" section, there is an entry that says "kernel: usbnet: Restore usb%d naming for cdc-ethernet devices with local MAC".

Does that mean that 24.10.1 has reversed the change that bit me last time, and will reinstate my cellular modem as "usb0" again rather than the "eth0" that 24.10.0 used? If so I need to formulate a mechanism to safely manage a remote sysupgrade where the base network configuration needs to be amended as part of the upgrade. Or plan another road trip...

dbedev · April 19, 2025, 1:00pm

Thanks for the update.

Upgraded 2x Tp Link Archer c7v2 (used as AP's) with the sysupgrade from the firmware selector 23.05.5 to 24.10.1. The update itself went ok however did have to manualy correct the config for things to function after the upgrade.

After the upgrade (with keep settings) the clients on the guest network failed to get IP adresses on the AP.

It seems this was caused by an additional device with a "br_" prefix that somehow got configured for my guest lan and this device was not attached to anything. Switching it back to original one configured for the correct path and unconfiguring the new "br_" one fixed it for me. (note that both devices had the same issue)

andywob · April 19, 2025, 3:46pm

Hi folks,
just upgraded from 24.10.0 to 24.10.1 via attended sysupgrade on my Xiaomi AX3600 without any issue.
Thanks to all developers and happy easter!
best
Andy

systemcrash · April 19, 2025, 7:14pm

This is a harmless error. It says that the kernel module for RPi lacks the default function mentioned. It must be fixed upstream.

github.com/raspberrypi/linux

Device 'grafx' does not have a release() function

opened 08:23AM - 10 Apr 25 UTC

Noltari

### Describe the bug bcm2711 devices show the following trace: ``` [ 0.21680…0] ------------[ cut here ]------------ [ 0.216807] Device 'grafx' does not have a release() function, it is broken and must be fixed. See Documentation/core-api/kobject.rst. [ 0.216863] WARNING: CPU: 0 PID: 1 at drivers/base/core.c:2516 device_release+0x80/0x90 [ 0.216887] Modules linked in: [ 0.216896] CPU: 0 PID: 1 Comm: swapper/0 Not tainted 6.6.85 #0 [ 0.216905] Hardware name: Raspberry Pi 4 Model B Rev 1.1 (DT) [ 0.216911] pstate: 60400005 (nZCv daif +PAN -UAO -TCO -DIT -SSBS BTYPE=--) [ 0.216919] pc : device_release+0x80/0x90 [ 0.216928] lr : device_release+0x80/0x90 [ 0.216936] sp : ffffffc080ccb6d0 [ 0.216940] x29: ffffffc080ccb6d0 x28: 0000000000000000 x27: ffffff8040d49810 [ 0.216953] x26: ffffff8040c904b8 x25: ffffff8040c904a0 x24: ffffffc0808a7f08 [ 0.216964] x23: ffffffc080a1a6d8 x22: 0000000000000000 x21: ffffffc080a1afe0 [ 0.216976] x20: 0000000000000000 x19: ffffff8040c900b8 x18: 000000000000009f [ 0.216987] x17: 206e656b6f726220 x16: 7369207469202c6e x15: ffffffc080b4ee88 [ 0.216998] x14: 00000000000001dd x13: 000000000000009f x12: 00000000ffffffea [ 0.217009] x11: 00000000ffffefff x10: ffffffc080ba6e88 x9 : ffffffc080b4ee30 [ 0.217020] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8 [ 0.217031] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc080ccb4d0 [ 0.217042] x2 : ffffffc080b4edc8 x1 : ffffffc080b4edc8 x0 : 000000000000007a [ 0.217053] Call trace: [ 0.217058] device_release+0x80/0x90 [ 0.217067] kobject_put+0xac/0x100 [ 0.217078] put_device+0x14/0x24 [ 0.217086] genpd_remove+0x16c/0x244 [ 0.217093] pm_genpd_remove+0x2c/0x50 [ 0.217099] bcm2835_power_probe+0x1f8/0x2b8 [ 0.217107] platform_probe+0x68/0xc4 [ 0.217118] really_probe+0x148/0x2b0 [ 0.217125] __driver_probe_device+0x78/0x128 [ 0.217131] driver_probe_device+0x40/0xdc [ 0.217138] __device_attach_driver+0xb8/0xf8 [ 0.217145] bus_for_each_drv+0x70/0xb8 [ 0.217151] __device_attach+0xa0/0x184 [ 0.217158] device_initial_probe+0x14/0x20 [ 0.217165] bus_probe_device+0xac/0xb0 [ 0.217171] device_add+0x5a8/0x760 [ 0.217177] platform_device_add+0x184/0x240 [ 0.217184] mfd_add_device+0x3e8/0x4c0 [ 0.217195] devm_mfd_add_devices+0xa0/0x118 [ 0.217202] bcm2835_pm_probe+0x144/0x1d8 [ 0.217210] platform_probe+0x68/0xc4 [ 0.217217] really_probe+0x148/0x2b0 [ 0.217224] __driver_probe_device+0x78/0x128 [ 0.217230] driver_probe_device+0x40/0xdc [ 0.217237] __driver_attach+0x90/0x160 [ 0.217243] bus_for_each_dev+0x64/0xa4 [ 0.217249] driver_attach+0x24/0x30 [ 0.217256] bus_add_driver+0xe4/0x208 [ 0.217262] driver_register+0x5c/0x124 [ 0.217269] __platform_driver_register+0x28/0x34 [ 0.217276] bcm2835_pm_driver_init+0x1c/0x28 [ 0.217286] do_one_initcall+0x6c/0x1fc [ 0.217294] kernel_init_freeable+0x208/0x2e4 [ 0.217306] kernel_init+0x28/0x1e4 [ 0.217313] ret_from_fork+0x10/0x20 [ 0.217320] ---[ end trace 0000000000000000 ]--- ``` ### Steps to reproduce the behaviour Install OpenWrt snapshot with kernel 6.6.85 from: https://downloads.openwrt.org/snapshots/targets/bcm27xx/bcm2711/ Boot and see the trace. ### Device (s) Raspberry Pi 4 Mod. B ### System OpenWrt (snapshots from main development branch) da7125f985dfe3cb0cf91e3c47f1ace88018e466 6.6.85 ### Logs ``` [ 0.000000] Booting Linux on physical CPU 0x0000000000 [0x410fd083] [ 0.000000] Linux version 6.6.85 (noltari@slimbook) (aarch64-openwrt-linux-musl-gcc (OpenWrt GCC 13.3.0 r27984+1-7afdbc0955) 13.3.0, GNU ld (GNU Binutils) 2.42) #0 SMP Thu Apr 10 07:38:18 2025 [ 0.000000] random: crng init done [ 0.000000] Machine model: Raspberry Pi 4 Model B Rev 1.1 [ 0.000000] Reserved memory: created CMA memory pool at 0x000000002ac00000, size 64 MiB [ 0.000000] OF: reserved mem: initialized node linux,cma, compatible id shared-dma-pool [ 0.000000] OF: reserved mem: 0x000000002ac00000..0x000000002ebfffff (65536 KiB) map reusable linux,cma [ 0.000000] OF: reserved mem: 0x000000003ef66100..0x000000003ef664ff (1 KiB) nomap non-reusable nvram@1 [ 0.000000] OF: reserved mem: 0x000000003ef66540..0x000000003ef66622 (0 KiB) nomap non-reusable nvram@0 [ 0.000000] NUMA: No NUMA configuration found [ 0.000000] NUMA: Faking a node at [mem 0x0000000000000000-0x00000000fbffffff] [ 0.000000] NUMA: NODE_DATA [mem 0xfb7f34c0-0xfb7f5fff] [ 0.000000] Zone ranges: [ 0.000000] DMA [mem 0x0000000000000000-0x000000003fffffff] [ 0.000000] DMA32 [mem 0x0000000040000000-0x00000000fbffffff] [ 0.000000] Normal empty [ 0.000000] Movable zone start for each node [ 0.000000] Early memory node ranges [ 0.000000] node 0: [mem 0x0000000000000000-0x000000003b3fffff] [ 0.000000] node 0: [mem 0x0000000040000000-0x00000000fbffffff] [ 0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x00000000fbffffff] [ 0.000000] On node 0, zone DMA32: 19456 pages in unavailable ranges [ 0.000000] On node 0, zone DMA32: 16384 pages in unavailable ranges [ 0.000000] percpu: Embedded 18 pages/cpu s36776 r8192 d28760 u73728 [ 0.000000] Detected PIPT I-cache on CPU0 [ 0.000000] CPU features: detected: Spectre-v2 [ 0.000000] CPU features: detected: Spectre-v4 [ 0.000000] CPU features: detected: Spectre-BHB [ 0.000000] CPU features: detected: ARM errata 1165522, 1319367, or 1530923 [ 0.000000] alternatives: applying boot alternatives [ 0.000000] Kernel command line: coherent_pool=1M 8250.nr_uarts=1 snd_bcm2835.enable_headphones=0 cgroup_disable=memory numa_policy=interleave bcm2708_fb.fbwidth=0 bcm2708_fb.fbheight=0 bcm2708_fb.fbswap=1 smsc95xx.macaddr=DC:A6:32:03:78:1E vc_mem.mem_base=0x3ec00000 vc_mem.mem_size=0x40000000 console=tty1 console=ttyAMA0,115200 root=PARTUUID=f2eaa71f-02 rootfstype=squashfs,ext4 rootwait [ 0.000000] cgroup: Disabling memory control group subsystem [ 0.000000] mempolicy: NUMA default policy overridden to 'interleave:0' [ 0.000000] Dentry cache hash table entries: 524288 (order: 10, 4194304 bytes, linear) [ 0.000000] Inode-cache hash table entries: 262144 (order: 9, 2097152 bytes, linear) [ 0.000000] Fallback order for Node 0: 0 [ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 996912 [ 0.000000] Policy zone: DMA32 [ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off [ 0.000000] software IO TLB: area num 4. [ 0.000000] software IO TLB: mapped [mem 0x0000000037400000-0x000000003b400000] (64MB) [ 0.000000] Memory: 3825832K/4050944K available (8512K kernel code, 932K rwdata, 2360K rodata, 448K init, 543K bss, 159576K reserved, 65536K cma-reserved) [ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1 [ 0.000000] rcu: Hierarchical RCU implementation. [ 0.000000] Tracing variant of Tasks RCU enabled. [ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies. [ 0.000000] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0 [ 0.000000] Root IRQ handler: gic_handle_irq [ 0.000000] GIC: Using split EOI/Deactivate mode [ 0.000000] rcu: srcu_init: Setting srcu_struct sizes based on contention. [ 0.000000] arch_timer: cp15 timer(s) running at 54.00MHz (phys). [ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0xc743ce346, max_idle_ns: 440795203123 ns [ 0.000000] sched_clock: 56 bits at 54MHz, resolution 18ns, wraps every 4398046511102ns [ 0.000100] Console: colour dummy device 80x25 [ 0.000106] printk: console [tty1] enabled [ 0.000349] Calibrating delay loop (skipped), value calculated using timer frequency.. 108.00 BogoMIPS (lpj=540000) [ 0.000362] pid_max: default: 32768 minimum: 301 [ 0.000529] Mount-cache hash table entries: 8192 (order: 4, 65536 bytes, linear) [ 0.000559] Mountpoint-cache hash table entries: 8192 (order: 4, 65536 bytes, linear) [ 0.001452] RCU Tasks Trace: Setting shift to 2 and lim to 1 rcu_task_cb_adjust=1 rcu_task_cpu_ids=4. [ 0.001560] rcu: Hierarchical SRCU implementation. [ 0.001567] rcu: Max phase no-delay instances is 1000. [ 0.001895] smp: Bringing up secondary CPUs ... [ 0.002118] Detected PIPT I-cache on CPU1 [ 0.002173] CPU1: Booted secondary processor 0x0000000001 [0x410fd083] [ 0.002407] Detected PIPT I-cache on CPU2 [ 0.002440] CPU2: Booted secondary processor 0x0000000002 [0x410fd083] [ 0.002651] Detected PIPT I-cache on CPU3 [ 0.002684] CPU3: Booted secondary processor 0x0000000003 [0x410fd083] [ 0.002717] smp: Brought up 1 node, 4 CPUs [ 0.002743] SMP: Total of 4 processors activated. [ 0.002749] CPU features: detected: 32-bit EL0 Support [ 0.002754] CPU features: detected: CRC32 instructions [ 0.002793] CPU features: emulated: Privileged Access Never (PAN) using TTBR0_EL1 switching [ 0.002802] CPU: All CPU(s) started at EL2 [ 0.002807] alternatives: applying system-wide alternatives [ 0.007825] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns [ 0.007860] futex hash table entries: 1024 (order: 4, 65536 bytes, linear) [ 0.008822] pinctrl core: initialized pinctrl subsystem [ 0.009458] NET: Registered PF_NETLINK/PF_ROUTE protocol family [ 0.010195] DMA: preallocated 1024 KiB GFP_KERNEL pool for atomic allocations [ 0.010303] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA pool for atomic allocations [ 0.010469] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations [ 0.010667] thermal_sys: Registered thermal governor 'step_wise' [ 0.010686] cpuidle: using governor ladder [ 0.010702] cpuidle: using governor menu [ 0.010792] ASID allocator initialised with 65536 entries [ 0.010866] Serial: AMBA PL011 UART driver [ 0.012517] /soc/interrupt-controller@40041000: Fixed dependency cycle(s) with /soc/interrupt-controller@40041000 [ 0.012848] bcm2835-mbox fe00b880.mailbox: mailbox enabled [ 0.029979] raspberrypi-firmware soc:firmware: Attached to firmware from 2025-02-17T20:03:07, variant start [ 0.039996] raspberrypi-firmware soc:firmware: Firmware hash is da7125f985dfe3cb0cf91e3c47f1ace88018e466 [ 0.052130] Modules: 29520 pages in range for non-PLT usage [ 0.052134] Modules: 521040 pages in range for PLT usage [ 0.052733] cryptd: max_cpu_qlen set to 1000 [ 0.053086] bcm2835-dma fe007000.dma-controller: DMA legacy API manager, dmachans=0x1 [ 0.053868] SCSI subsystem initialized [ 0.053943] usbcore: registered new interface driver usbfs [ 0.053961] usbcore: registered new interface driver hub [ 0.053980] usbcore: registered new device driver usb [ 0.054100] mc: Linux media interface: v0.10 [ 0.054119] videodev: Linux video capture interface: v2.00 [ 0.054134] pps_core: LinuxPPS API ver. 1 registered [ 0.054139] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it> [ 0.054150] PTP clock support registered [ 0.055181] clocksource: Switched to clocksource arch_sys_counter [ 0.056887] NET: Registered PF_INET protocol family [ 0.057104] IP idents hash table entries: 65536 (order: 7, 524288 bytes, linear) [ 0.058847] tcp_listen_portaddr_hash hash table entries: 2048 (order: 3, 32768 bytes, linear) [ 0.058886] Table-perturb hash table entries: 65536 (order: 6, 262144 bytes, linear) [ 0.058900] TCP established hash table entries: 32768 (order: 6, 262144 bytes, linear) [ 0.058995] TCP bind hash table entries: 32768 (order: 8, 1048576 bytes, linear) [ 0.060123] TCP: Hash tables configured (established 32768 bind 32768) [ 0.060385] MPTCP token hash table entries: 4096 (order: 4, 98304 bytes, linear) [ 0.060561] UDP hash table entries: 2048 (order: 4, 65536 bytes, linear) [ 0.060594] UDP-Lite hash table entries: 2048 (order: 4, 65536 bytes, linear) [ 0.060733] NET: Registered PF_UNIX/PF_LOCAL protocol family [ 0.060771] PCI: CLS 0 bytes, default 64 [ 0.061696] workingset: timestamp_bits=42 max_order=20 bucket_order=0 [ 0.062059] squashfs: version 4.0 (2009/01/31) Phillip Lougher [ 0.089230] pinctrl-bcm2835 fe200000.gpio: GPIO_OUT persistence: yes [ 0.090111] brcm-pcie fd500000.pcie: host bridge /scb/pcie@7d500000 ranges: [ 0.090126] brcm-pcie fd500000.pcie: No bus range found for /scb/pcie@7d500000, using [bus 00-ff] [ 0.090147] brcm-pcie fd500000.pcie: MEM 0x0600000000..0x067fffffff -> 0x0080000000 [ 0.090166] brcm-pcie fd500000.pcie: IB MEM 0x0000000000..0x00bfffffff -> 0x0400000000 [ 0.090802] brcm-pcie fd500000.pcie: PCI host bridge to bus 0000:00 [ 0.090813] pci_bus 0000:00: root bus resource [bus 00-ff] [ 0.090821] pci_bus 0000:00: root bus resource [mem 0x600000000-0x67fffffff] (bus address [0x80000000-0xffffffff]) [ 0.090847] pci 0000:00:00.0: [14e4:2711] type 01 class 0x060400 [ 0.090889] pci 0000:00:00.0: PME# supported from D0 D3hot [ 0.092302] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring [ 0.092360] pci_bus 0000:01: supply vpcie3v3 not found, using dummy regulator [ 0.092425] pci_bus 0000:01: supply vpcie3v3aux not found, using dummy regulator [ 0.092450] pci_bus 0000:01: supply vpcie12v not found, using dummy regulator [ 0.206784] brcm-pcie fd500000.pcie: link up, 5.0 GT/s PCIe x1 (SSC) [ 0.206851] pci 0000:01:00.0: [1106:3483] type 00 class 0x0c0330 [ 0.206908] pci 0000:01:00.0: reg 0x10: [mem 0x00000000-0x00000fff 64bit] [ 0.207032] pci 0000:01:00.0: PME# supported from D0 D3cold [ 0.207222] pci_bus 0000:01: busn_res: [bus 01-ff] end is updated to 01 [ 0.207243] pci 0000:00:00.0: BAR 8: assigned [mem 0x600000000-0x6000fffff] [ 0.207253] pci 0000:01:00.0: BAR 0: assigned [mem 0x600000000-0x600000fff 64bit] [ 0.207299] pci 0000:00:00.0: PCI bridge to [bus 01] [ 0.207306] pci 0000:00:00.0: bridge window [mem 0x600000000-0x6000fffff] [ 0.207403] pcieport 0000:00:00.0: enabling device (0000 -> 0002) [ 0.207465] pcieport 0000:00:00.0: PME: Signaling with IRQ 26 [ 0.207578] pcieport 0000:00:00.0: AER: enabled with IRQ 26 [ 0.207872] bcm2708_fb soc:fb: Unable to determine number of FBs. Disabling driver. [ 0.207881] bcm2708_fb: probe of soc:fb failed with error -2 [ 0.210624] Serial: 8250/16550 driver, 1 ports, IRQ sharing enabled [ 0.211110] iproc-rng200 fe104000.rng: hwrng registered [ 0.211164] vc-mem: phys_addr:0x00000000 mem_base=0x3ec00000 mem_size:0x40000000(1024 MiB) [ 0.211382] rpi-gpiomem fe200000.gpiomem: window base 0xfe200000 size 0x00001000 [ 0.211421] rpi-gpiomem fe200000.gpiomem: initialised 1 regions as /dev/gpiomem [ 0.214997] brd: module loaded [ 0.216559] loop: module loaded [ 0.216800] ------------[ cut here ]------------ [ 0.216807] Device 'grafx' does not have a release() function, it is broken and must be fixed. See Documentation/core-api/kobject.rst. [ 0.216863] WARNING: CPU: 0 PID: 1 at drivers/base/core.c:2516 device_release+0x80/0x90 [ 0.216887] Modules linked in: [ 0.216896] CPU: 0 PID: 1 Comm: swapper/0 Not tainted 6.6.85 #0 [ 0.216905] Hardware name: Raspberry Pi 4 Model B Rev 1.1 (DT) [ 0.216911] pstate: 60400005 (nZCv daif +PAN -UAO -TCO -DIT -SSBS BTYPE=--) [ 0.216919] pc : device_release+0x80/0x90 [ 0.216928] lr : device_release+0x80/0x90 [ 0.216936] sp : ffffffc080ccb6d0 [ 0.216940] x29: ffffffc080ccb6d0 x28: 0000000000000000 x27: ffffff8040d49810 [ 0.216953] x26: ffffff8040c904b8 x25: ffffff8040c904a0 x24: ffffffc0808a7f08 [ 0.216964] x23: ffffffc080a1a6d8 x22: 0000000000000000 x21: ffffffc080a1afe0 [ 0.216976] x20: 0000000000000000 x19: ffffff8040c900b8 x18: 000000000000009f [ 0.216987] x17: 206e656b6f726220 x16: 7369207469202c6e x15: ffffffc080b4ee88 [ 0.216998] x14: 00000000000001dd x13: 000000000000009f x12: 00000000ffffffea [ 0.217009] x11: 00000000ffffefff x10: ffffffc080ba6e88 x9 : ffffffc080b4ee30 [ 0.217020] x8 : 0000000000017fe8 x7 : c0000000ffffefff x6 : 0000000000057fa8 [ 0.217031] x5 : 0000000000000fff x4 : 0000000000000000 x3 : ffffffc080ccb4d0 [ 0.217042] x2 : ffffffc080b4edc8 x1 : ffffffc080b4edc8 x0 : 000000000000007a [ 0.217053] Call trace: [ 0.217058] device_release+0x80/0x90 [ 0.217067] kobject_put+0xac/0x100 [ 0.217078] put_device+0x14/0x24 [ 0.217086] genpd_remove+0x16c/0x244 [ 0.217093] pm_genpd_remove+0x2c/0x50 [ 0.217099] bcm2835_power_probe+0x1f8/0x2b8 [ 0.217107] platform_probe+0x68/0xc4 [ 0.217118] really_probe+0x148/0x2b0 [ 0.217125] __driver_probe_device+0x78/0x128 [ 0.217131] driver_probe_device+0x40/0xdc [ 0.217138] __device_attach_driver+0xb8/0xf8 [ 0.217145] bus_for_each_drv+0x70/0xb8 [ 0.217151] __device_attach+0xa0/0x184 [ 0.217158] device_initial_probe+0x14/0x20 [ 0.217165] bus_probe_device+0xac/0xb0 [ 0.217171] device_add+0x5a8/0x760 [ 0.217177] platform_device_add+0x184/0x240 [ 0.217184] mfd_add_device+0x3e8/0x4c0 [ 0.217195] devm_mfd_add_devices+0xa0/0x118 [ 0.217202] bcm2835_pm_probe+0x144/0x1d8 [ 0.217210] platform_probe+0x68/0xc4 [ 0.217217] really_probe+0x148/0x2b0 [ 0.217224] __driver_probe_device+0x78/0x128 [ 0.217230] driver_probe_device+0x40/0xdc [ 0.217237] __driver_attach+0x90/0x160 [ 0.217243] bus_for_each_dev+0x64/0xa4 [ 0.217249] driver_attach+0x24/0x30 [ 0.217256] bus_add_driver+0xe4/0x208 [ 0.217262] driver_register+0x5c/0x124 [ 0.217269] __platform_driver_register+0x28/0x34 [ 0.217276] bcm2835_pm_driver_init+0x1c/0x28 [ 0.217286] do_one_initcall+0x6c/0x1fc [ 0.217294] kernel_init_freeable+0x208/0x2e4 [ 0.217306] kernel_init+0x28/0x1e4 [ 0.217313] ret_from_fork+0x10/0x20 [ 0.217320] ---[ end trace 0000000000000000 ]--- [ 0.218294] bcmgenet fd580000.ethernet: GENET 5.0 EPHY: 0x0000 [ 0.544753] unimac-mdio unimac-mdio.-19: Broadcom UniMAC MDIO bus [ 0.546363] xhci_hcd 0000:01:00.0: enabling device (0000 -> 0002) [ 0.546455] xhci_hcd 0000:01:00.0: xHCI Host Controller [ 0.546470] xhci_hcd 0000:01:00.0: new USB bus registered, assigned bus number 1 [ 0.547374] xhci_hcd 0000:01:00.0: hcc params 0x002841eb hci version 0x100 quirks 0x0300240000000890 [ 0.547794] xhci_hcd 0000:01:00.0: xHCI Host Controller [ 0.547806] xhci_hcd 0000:01:00.0: new USB bus registered, assigned bus number 2 [ 0.547817] xhci_hcd 0000:01:00.0: Host supports USB 3.0 SuperSpeed [ 0.547950] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 6.06 [ 0.547961] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 0.547969] usb usb1: Product: xHCI Host Controller [ 0.547975] usb usb1: Manufacturer: Linux 6.6.85 xhci-hcd [ 0.547981] usb usb1: SerialNumber: 0000:01:00.0 [ 0.548149] hub 1-0:1.0: USB hub found [ 0.548197] hub 1-0:1.0: 1 port detected [ 0.548497] usb usb2: New USB device found, idVendor=1d6b, idProduct=0003, bcdDevice= 6.06 [ 0.548507] usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1 [ 0.548515] usb usb2: Product: xHCI Host Controller [ 0.548521] usb usb2: Manufacturer: Linux 6.6.85 xhci-hcd [ 0.548527] usb usb2: SerialNumber: 0000:01:00.0 [ 0.548684] hub 2-0:1.0: USB hub found [ 0.548731] hub 2-0:1.0: 4 ports detected [ 0.549165] dwc_otg: version 3.00a 10-AUG-2012 (platform bus) [ 0.549396] usbcore: registered new interface driver uas [ 0.549427] usbcore: registered new interface driver usb-storage [ 0.549467] mousedev: PS/2 mouse device common for all mice [ 0.549770] bcm2835-wdt bcm2835-wdt: Broadcom BCM2835 watchdog timer [ 0.550505] sdhci: Secure Digital Host Controller Interface driver [ 0.550514] sdhci: Copyright(c) Pierre Ossman [ 0.550733] mmc-bcm2835 fe300000.mmcnr: could not get clk, deferring probe [ 0.550916] sdhci-pltfm: SDHCI platform and OF driver helper [ 0.556926] NET: Registered PF_INET6 protocol family [ 0.557429] Segment Routing with IPv6 [ 0.557449] In-situ OAM (IOAM) with IPv6 [ 0.557494] NET: Registered PF_PACKET protocol family [ 0.557522] 8021q: 802.1Q VLAN Support v1.8 [ 0.568813] Key type .fscrypt registered [ 0.568842] Key type fscrypt-provisioning registered [ 0.571748] uart-pl011 fe201000.serial: there is not valid maps for state default [ 0.571918] uart-pl011 fe201000.serial: cts_event_workaround enabled [ 0.572070] fe201000.serial: ttyAMA0 at MMIO 0xfe201000 (irq = 32, base_baud = 0) is a PL011 rev3 [ 0.572095] printk: console [ttyAMA0] enabled [ 2.093722] bcm2835-power bcm2835-power: Broadcom BCM2835 power domains driver [ 2.101236] mmc-bcm2835 fe300000.mmcnr: mmc_debug:0 mmc_debug2:0 [ 2.107260] mmc-bcm2835 fe300000.mmcnr: DMA channel allocated [ 2.138689] of_cfs_init [ 2.141189] of_cfs_init: OK [ 2.144064] clk: Disabling unused clocks [ 2.148332] uart-pl011 fe201000.serial: no DMA platform data [ 2.187291] mmc0: SDHCI controller on fe340000.mmc [fe340000.mmc] using ADMA [ 2.194459] Waiting for root device PARTUUID=f2eaa71f-02... [ 2.236163] mmc1: new high speed SDIO card at address 0001 [ 2.250603] mmc0: new high speed SDHC card at address ed84 [ 2.254740] usb 1-1: new high-speed USB device number 2 using xhci_hcd [ 2.256507] mmcblk0: mmc0:ed84 SE04G 3.64 GiB [ 2.267653] mmcblk0: p1 p2 [ 2.270560] mmcblk0: mmc0:ed84 SE04G 3.64 GiB [ 2.292834] EXT4-fs (mmcblk0p2): mounted filesystem ff313567-e9f1-5a5d-9895-3ba130b4a864 ro with ordered data mode. Quota mode: disabled. [ 2.305276] VFS: Mounted root (ext4 filesystem) readonly on device 179:2. [ 2.312287] Freeing unused kernel memory: 448K [ 2.316840] Run /sbin/init as init process [ 2.391756] init: Console is alive [ 2.395272] init: - watchdog - [ 2.437376] usb 1-1: New USB device found, idVendor=2109, idProduct=3431, bcdDevice= 4.21 [ 2.445586] usb 1-1: New USB device strings: Mfr=0, Product=1, SerialNumber=0 [ 2.452717] usb 1-1: Product: USB2.0 Hub [ 2.457837] hub 1-1:1.0: USB hub found [ 2.461833] hub 1-1:1.0: 4 ports detected [ 2.553877] kmodloader: loading kernel modules from /etc/modules-boot.d/* [ 2.570174] kmodloader: done loading kernel modules from /etc/modules-boot.d/* [ 2.579944] init: - preinit - [ 2.661529] bcmgenet fd580000.ethernet: configuring instance for external RGMII (RX delay) [ 2.670983] bcmgenet fd580000.ethernet eth0: Link is Down Press the [f] key and hit [enter] to enter failsafe mode Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level [ 6.946115] mount_root: mounting /dev/root with options [ 6.997297] EXT4-fs (mmcblk0p2): re-mounted ff313567-e9f1-5a5d-9895-3ba130b4a864 r/w. Quota mode: disabled. [ 7.026406] insmod: module is already loaded - fat [ 7.032479] insmod: module is already loaded - vfat sh: out of range [ 7.048344] urandom-seed: Seed file not found (/etc/urandom.seed) [ 7.207243] procd: - early - [ 7.210178] procd: - watchdog - [ 7.739340] procd: - watchdog - [ 7.743110] procd: - ubus - [ 7.896488] procd: - init - Please press Enter to activate this console. [ 7.991657] kmodloader: loading kernel modules from /etc/modules.d/* [ 8.009727] hid: raw HID events driver (C) Jiri Kosina [ 8.015815] snd_bcm2835: module is from the staging directory, the quality is unknown, you have been warned. [ 8.026977] bcm2835_audio bcm2835_audio: card created with 8 channels [ 8.042464] brcmutil: loading out-of-tree module taints kernel. [ 8.049145] Loading modules backported from Linux version v6.12.6-0-ge9d65b48ce1a [ 8.056645] Backport generated by backports.git v6.1.110-1-35-g410656ef04d2 [ 8.064922] usbcore: registered new interface driver lan78xx [ 8.073571] usbcore: registered new interface driver usbhid [ 8.079208] usbhid: USB HID core driver [ 8.109084] PPP generic driver version 2.4.2 [ 8.113784] NET: Registered PF_PPPOX protocol family [ 8.130919] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43455-sdio for chip BCM4345/6 [ 8.139760] usbcore: registered new interface driver brcmfmac [ 8.146126] brcmfmac mmc1:0001:1: Direct firmware load for brcm/brcmfmac43455-sdio.raspberrypi,4-model-b.bin failed with error -2 [ 8.157794] brcmfmac mmc1:0001:1: Falling back to sysfs fallback for: brcm/brcmfmac43455-sdio.raspberrypi,4-model-b.bin [ 8.170151] kmodloader: done loading kernel modules from /etc/modules.d/* [ 8.372835] brcmfmac: brcmf_c_process_txcap_blob: no txcap_blob available (err=-2) [ 8.380778] brcmfmac: brcmf_c_preinit_dcmds: Firmware: BCM4345/6 wl0: Jul 29 2022 02:15:20 version 7.45.250 (70e9766 CY) FWID 01-e53e306b [ 12.343492] bcmgenet fd580000.ethernet: configuring instance for external RGMII (RX delay) [ 12.352745] bcmgenet fd580000.ethernet eth0: Link is Down [ 12.358188] br-lan: port 1(eth0) entered blocking state [ 12.363412] br-lan: port 1(eth0) entered disabled state [ 12.368684] bcmgenet fd580000.ethernet eth0: entered allmulticast mode [ 12.375339] bcmgenet fd580000.ethernet eth0: entered promiscuous mode BusyBox v1.37.0 (2025-04-10 07:28:36 UTC) built-in shell (ash) _______ ________ __ | |.-----.-----.-----.| | | |.----.| |_ | - || _ | -__| || | | || _|| _| |_______|| __|_____|__|__||________||__| |____| |__| W I R E L E S S F R E E D O M ----------------------------------------------------- OpenWrt SNAPSHOT, r29139+38-65b8a978de ----------------------------------------------------- === WARNING! ===================================== There is no root password defined on this device! Use the "passwd" command to set up a new password in order to prevent unauthorized SSH logins. -------------------------------------------------- OpenWrt recently switched to the "apk" package manager! OPKG Command APK Equivalent Description ------------------------------------------------------------------ opkg install <pkg> apk add <pkg> Install a package opkg remove <pkg> apk del <pkg> Remove a package opkg upgrade apk upgrade Upgrade all packages opkg files <pkg> apk info -L <pkg> List package contents opkg list-installed apk info List installed packages opkg update apk update Update package lists opkg search <pkg> apk search <pkg> Search for packages ------------------------------------------------------------------ For more https://openwrt.org/docs/guide-user/additional-software/opkg-to-apk-cheatsheet root@OpenWrt:~# ``` ### Additional context _No response_

hunghvu · April 20, 2025, 1:30am

mx4xxx series has dual firmware setup. When doing a sysupgrade, both partitions are upgraded. In other words, you need to do a mtd flash to install OpenWRT on both partitions. If it is 1 OEM and 1 OpenWRT, the upgrade fails (blinking green, soft brick).

When it is soft bricked, you need to do 30/30/30 reset so the router returns to its most current OpenWRT installation.

nickyng · April 20, 2025, 1:47am

oh i see...so is there an option to just upgrade the partition that is running OpenWRT and leave the other OEM partition as it is ??
