Wifi-OpenVpn- Exclude IP

Installing and Using OpenWrt
1

Hello,
I have 2 routers (ISP and another one with OpenWRT that has OpenVPN enabled) connected through WiFi. I have changed the gateway in the OpenWRT (rest is the default configuration) and there are several devices connected to its WiFi.
I tried to exclude some of those devices (through IP and through MAC) from passing to the VPN but didn´t achieve success (all devices still pass through the VPN)

OpenWrt 24.10.2, r28739-d9340319c6
 -----------------------------------------------------
root@OpenWrt:~# ip route show
0.0.0.0/1 via 10.17.110.1 dev tun0
default via 192.168.1.1 dev phy0-sta0 proto static src 192.168.1.140
10.17.110.0/24 dev tun0 proto kernel scope link src 10.17.110.28
128.0.0.0/1 via 10.17.110.1 dev tun0
192.168.1.0/24 dev phy0-sta0 proto kernel scope link src 192.168.1.140
192.168.100.0/24 dev br-lan proto kernel scope link src 192.168.100.1
196.245.54.178 via 192.168.1.1 dev phy0-sta0

Is there a way to achieve excluding some of those devices from using the VPN while the rest of the traffic does pass through it?
Any help or guidance will be much appreciated, if there a need for additional information don´t hesitate to ask.

Thank you.

2

You need policy based routing. This will allow you to set the specific devices that should bypass the VPN. (you should probably set a DHCP reservation for those devices so that you can guarantee they are always using the same IP).

3

it is the option that I have been trying to configure but I can't do it, I don't know if it is because the active interface is wwan and it does not recognize pbr or other configurations that I do not do correctly, would you be so kind as to send me an example, I would greatly appreciate it because I am lost in this.

4

I am attaching this image in case it can clarify my installation

Captura de pantalla 2025-07-25 171540
Captura de pantalla 2025-07-25 171540922×579 12.8 KB

5

Let's say you want hosts 101 and 102 to bypass the VPN.

#/etc/config/network

config rule
        option in 'lan'
        option src '192.168.100.101/32'
        option lookup '100'

config rule
        option in 'lan'
        option src '192.168.100.102/32'
        option lookup '100'

config route
        option interface 'wwan' # <-- make sure this is the correct logical wan interface name
        option target '0.0.0.0/0'
        option gateway '192.168.1.1'
        option table '100'

# This is to avoid some unwanted side effects
config route
        option interface 'lan'
        option target '192.168.100.0/24'
        option table '100'
6

Configuration installed and working, like tithes in these parts, he who knows knows, I went crazy looking for and putting into practice other operations but I couldn't get the correction right, thank you very much.
