I'm trying to get either a Netopia 3342/3352 modem working, or an Alcatel speedtouch usb modem working to have a low powered modem that can run for a while on my RBPi's UPS.
I don't actually have the speedtouch yet, so that may be different, but from what I understand, for the netopia I should put the firmware .bin for it in /lib/firmware (I have) and a config file (cxracru) in /etc. I also have the kmod-usb-atm-cxacru, and br2684ctl packages.
Can anyone help me with this project? I'm stuck with ADSL for the next year at least, and I picked up the modems for a couple dollars each hoping they would be low power solutions that will work, but its not a huge deal if I can't get either one working. It would be cool though, especially since I now have 6 18650 cells on the UPS board and would like to attempt a solar powered solution sometime in the next few months.
This is what I currently have when plugging in the modem:
[133479.022938] /etc/init.d/persistentlucistatistics: stop> /boot/psave/rrd [create</tmp/rrd:1.4M:1:0]
[133479.983466] /etc/init.d/persistentnlbwmon: saving-service-data-save-psave> /boot/psave/nlbwmon
[135531.688933] usb 1-1.3: new full-speed USB device number 4 using xhci_hcd
[135531.816101] usb 1-1.3: New USB device found, idVendor=100d, idProduct=3342, bcdDevice= 1.00
[135531.824685] usb 1-1.3: New USB device strings: Mfr=1, Product=2, SerialNumber=3
[135531.832117] usb 1-1.3: Product: USB NET CARD
[135531.836773] usb 1-1.3: Manufacturer: -
[135531.840742] usb 1-1.3: SerialNumber: 16838728
[135531.853648] cxacru 1-1.3:1.0: ignoring cx82310_eth device
Bus 001 Device 004: ID 100d:3342 Netopia, Inc. Cayman 3352 DSL Modem
Device Descriptor:
bLength 18
bDescriptorType 1
bcdUSB 1.10
bDeviceClass 255 Vendor Specific Class
bDeviceSubClass 0
bDeviceProtocol 0
bMaxPacketSize0 64
idVendor 0x100d Netopia, Inc.
idProduct 0x3342 Cayman 3352 DSL Modem
bcdDevice 1.00
iManufacturer 1 -
iProduct 2 USB NET CARD
iSerial 3 16838728
bNumConfigurations 1
Configuration Descriptor:
bLength 9
bDescriptorType 2
wTotalLength 67
bNumInterfaces 1
bConfigurationValue 1
iConfiguration 0
bmAttributes 0x80
(Bus Powered)
MaxPower 500mA
Interface Descriptor:
bLength 9
bDescriptorType 4
bInterfaceNumber 0
bAlternateSetting 0
bNumEndpoints 7
bInterfaceClass 0 (Defined at Interface level)
bInterfaceSubClass 0
bInterfaceProtocol 0
iInterface 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x81 EP 1 IN
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x01 EP 1 OUT
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x82 EP 2 IN
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x02 EP 2 OUT
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x83 EP 3 IN
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x03 EP 3 OUT
bmAttributes 2
Transfer Type Bulk
Synch Type None
Usage Type Data
wMaxPacketSize 0x0040 1x 64 bytes
bInterval 0
Endpoint Descriptor:
bLength 7
bDescriptorType 5
bEndpointAddress 0x84 EP 4 IN
bmAttributes 3
Transfer Type Interrupt
Synch Type None
Usage Type Data
wMaxPacketSize 0x0008 1x 8 bytes
bInterval 200
Device Status: 0x0001
Self Powered
