Here full boot log
Starting kernel ...
[ 0.000000] Linux version 5.10.90 (lucky@6700K) (mipsel-openwrt-linux-musl-gcc (OpenWrt GCC 11.2.0 r18541-7f2052ef22) 11.2.0, GNU ld (GNU Binutils) 2.37) #0 SMP Thu Jan 13 09:45:20 2022
[ 0.000000] SoC Type: MediaTek MT7621 ver:1 eco:3
[ 0.000000] printk: bootconsole [early0] enabled
[ 0.000000] CPU0 revision is: 0001992f (MIPS 1004Kc)
[ 0.000000] MIPS: machine is D-Link DIR-2150 R1
[ 0.000000] Initrd not found or empty - disabling initrd
[ 0.000000] VPE topology {2,2} total 4
[ 0.000000] Primary instruction cache 32kB, VIPT, 4-way, linesize 32 bytes.
[ 0.000000] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes
[ 0.000000] MIPS secondary cache 256kB, 8-way, linesize 32 bytes.
[ 0.000000] Zone ranges:
[ 0.000000] Normal [mem 0x0000000000000000-0x0000000007ffffff]
[ 0.000000] HighMem empty
[ 0.000000] Movable zone start for each node
[ 0.000000] Early memory node ranges
[ 0.000000] node 0: [mem 0x0000000000000000-0x0000000007ffffff]
[ 0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x0000000007ffffff]
[ 0.000000] percpu: Embedded 15 pages/cpu s30096 r8192 d23152 u61440
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 32480
[ 0.000000] Kernel command line: console=ttyS0,57600 rootfstype=squashfs,jffs2
[ 0.000000] Dentry cache hash table entries: 16384 (order: 4, 65536 bytes, linear)
[ 0.000000] Inode-cache hash table entries: 8192 (order: 3, 32768 bytes, linear)
[ 0.000000] Writing ErrCtl register=0001084c
[ 0.000000] Readback ErrCtl register=0001084c
[ 0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[ 0.000000] Memory: 115704K/131072K available (6661K kernel code, 623K rwdata, 1352K rodata, 4916K init, 235K bss, 15368K reserved, 0K cma-reserved, 0K highmem)
[ 0.000000] SLUB: HWalign=32, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] rcu: Hierarchical RCU implementation.
[ 0.000000] Tracing variant of Tasks RCU enabled.
[ 0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[ 0.000000] NR_IRQS: 256
[ 0.000000] random: get_random_bytes called from start_kernel+0x3cc/0x5e4 with crng_init=0
[ 0.000000] CPU Clock: 880MHz
[ 0.000000] clocksource: GIC: mask: 0xffffffffffffffff max_cycles: 0xcaf478abb4, max_idle_ns: 440795247997 ns
[ 0.000012] sched_clock: 64 bits at 880MHz, resolution 1ns, wraps every 4398046511103ns
[ 0.015857] clocksource: MIPS: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 4343773742 ns
[ 0.033725] Calibrating delay loop... 586.13 BogoMIPS (lpj=2930688)
[ 0.106051] pid_max: default: 32768 minimum: 301
[ 0.115360] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes, linear)
[ 0.129765] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes, linear)
[ 0.147750] rcu: Hierarchical SRCU implementation.
[ 0.157515] dyndbg: Ignore empty _ddebug table in a CONFIG_DYNAMIC_DEBUG_CORE build
[ 0.172999] smp: Bringing up secondary CPUs ...
[ 0.182558] Primary instruction cache 32kB, VIPT, 4-way, linesize 32 bytes.
[ 0.182569] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes
[ 0.182580] MIPS secondary cache 256kB, 8-way, linesize 32 bytes.
[ 0.182686] CPU1 revision is: 0001992f (MIPS 1004Kc)
[ 0.242912] Synchronize counters for CPU 1: done.
[ 0.304878] Primary instruction cache 32kB, VIPT, 4-way, linesize 32 bytes.
[ 0.304887] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes
[ 0.304894] MIPS secondary cache 256kB, 8-way, linesize 32 bytes.
[ 0.304942] CPU2 revision is: 0001992f (MIPS 1004Kc)
[ 0.363855] Synchronize counters for CPU 2: done.
[ 0.424044] Primary instruction cache 32kB, VIPT, 4-way, linesize 32 bytes.
[ 0.424053] Primary data cache 32kB, 4-way, PIPT, no aliases, linesize 32 bytes
[ 0.424060] MIPS secondary cache 256kB, 8-way, linesize 32 bytes.
[ 0.424113] CPU3 revision is: 0001992f (MIPS 1004Kc)
[ 0.483420] Synchronize counters for CPU 3: done.
[ 0.543024] smp: Brought up 1 node, 4 CPUs
[ 0.555021] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.574516] futex hash table entries: 1024 (order: 3, 32768 bytes, linear)
[ 0.588340] pinctrl core: initialized pinctrl subsystem
[ 0.600344] NET: Registered protocol family 16
[ 0.611340] cpuidle: using governor teo
[ 0.639198] random: fast init done
[ 0.662232] clocksource: Switched to clocksource GIC
[ 0.673934] NET: Registered protocol family 2
[ 0.683129] IP idents hash table entries: 2048 (order: 2, 16384 bytes, linear)
[ 0.698016] tcp_listen_portaddr_hash hash table entries: 512 (order: 0, 6144 bytes, linear)
[ 0.714583] TCP established hash table entries: 1024 (order: 0, 4096 bytes, linear)
[ 0.729725] TCP bind hash table entries: 1024 (order: 1, 8192 bytes, linear)
[ 0.743719] TCP: Hash tables configured (established 1024 bind 1024)
[ 0.756464] UDP hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.769352] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear)
[ 0.783381] NET: Registered protocol family 1
[ 0.791919] PCI: CLS 0 bytes, default 32
[ 5.329346] workingset: timestamp_bits=14 max_order=15 bucket_order=1
[ 5.346001] squashfs: version 4.0 (2009/01/31) Phillip Lougher
[ 5.357481] jffs2: version 2.2 (NAND) (SUMMARY) (LZMA) (RTIME) (CMODE_PRIORITY) (c) 2001-2006 Red Hat, Inc.
[ 5.379116] mt7621_gpio 1e000600.gpio: registering 32 gpios
[ 5.390506] mt7621_gpio 1e000600.gpio: registering 32 gpios
[ 5.401875] mt7621_gpio 1e000600.gpio: registering 32 gpios
[ 5.413789] Serial: 8250/16550 driver, 3 ports, IRQ sharing disabled
[ 5.427872] printk: console [ttyS0] disabled
[ 5.436400] 1e000c00.uartlite: ttyS0 at MMIO 0x1e000c00 (irq = 19, base_baud = 3125000) is a 16550A
[ 5.454305] printk: console [ttyS0] enabled
[ 5.454305] printk: console [ttyS0] enabled
[ 5.470845] printk: bootconsole [early0] disabled
[ 5.470845] printk: bootconsole [early0] disabled
[ 5.491834] mt7621-nand 1e003000.nand: Using programmed access timing: 31c07388
[ 5.506660] nand: device found, Manufacturer ID: 0xf8, Chip ID: 0xf1
[ 5.519312] nand: Unknown FMND1G08U3D
[ 5.526606] nand: 128 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64
[ 5.541675] mt7621-nand 1e003000.nand: ECC strength adjusted to 4 bits
[ 5.554712] mt7621-nand 1e003000.nand: Using programmed access timing: 21005134
[ 5.569276] mt7621-nand 1e003000.nand: Using programmed access timing: 21005134
[ 5.583831] Scanning device for bad blocks
[ 6.247611] 6 fixed-partitions partitions found on MTD device mt7621-nand
[ 6.261126] Creating 6 MTD partitions on "mt7621-nand":
[ 6.271535] 0x000000000000-0x000000080000 : "u-boot"
[ 6.282463] 0x000000080000-0x000000100000 : "config"
[ 6.293360] 0x000000100000-0x000000140000 : "factory"
[ 6.304441] 0x000000140000-0x000001f40000 : "Kernal"
[ 6.317548] 2 uimage-fw partitions found on MTD device Kernal
[ 6.329041] Creating 2 MTD partitions on "Kernal":
[ 6.338600] 0x000000000000-0x0000001e0000 : "kernel"
[ 6.349349] 0x0000001e0000-0x000001e00000 : "rootfs"
[ 6.360142] mtd: device 5 (rootfs) set to be root filesystem
[ 6.371488] 1 squashfs-split partitions found on MTD device rootfs
[ 6.383808] 0x000000d60000-0x000001e00000 : "rootfs_data"
[ 6.395465] 0x000000320000-0x000001000000 : "RootFS"
[ 6.406335] 0x000001000000-0x000001700000 : "unknown"
[ 6.424925] libphy: Fixed MDIO Bus: probed
[ 6.473515] libphy: mdio: probed
[ 6.480795] mt7530 mdio-bus:1f: MT7530 adapts as multi-chip module
[ 6.496616] mtk_soc_eth 1e100000.ethernet eth0: mediatek frame engine at 0xbe100000, irq 21
[ 6.516492] mt7621-pci 1e140000.pcie: host bridge /pcie@1e140000 ranges:
[ 6.529879] mt7621-pci 1e140000.pcie: No bus range found for /pcie@1e140000, using [bus 00-ff]
[ 6.547403] mt7621-pci 1e140000.pcie: MEM 0x0060000000..0x006fffffff -> 0x0000000000
[ 6.563705] mt7621-pci 1e140000.pcie: IO 0x001e160000..0x001e16ffff -> 0x0000000000
[ 6.580079] mt7621-pci 1e140000.pcie: Parsing DT failed
[ 6.592648] NET: Registered protocol family 10
[ 6.603038] Segment Routing with IPv6
[ 6.610413] NET: Registered protocol family 17
[ 6.619658] 8021q: 802.1Q VLAN Support v1.8
[ 6.631250] mt7530 mdio-bus:1f: MT7530 adapts as multi-chip module
[ 6.736923] libphy: dsa slave smi: probed
[ 6.745540] mt7530 mdio-bus:1f lan4 (uninitialized): PHY [dsa-0.0:00] driver [Generic PHY] (irq=POLL)
[ 6.765610] mt7530 mdio-bus:1f lan3 (uninitialized): PHY [dsa-0.0:01] driver [Generic PHY] (irq=POLL)
[ 6.785802] mt7530 mdio-bus:1f lan2 (uninitialized): PHY [dsa-0.0:02] driver [Generic PHY] (irq=POLL)
[ 6.805822] mt7530 mdio-bus:1f lan1 (uninitialized): PHY [dsa-0.0:03] driver [Generic PHY] (irq=POLL)
[ 6.825939] mt7530 mdio-bus:1f wan (uninitialized): PHY [dsa-0.0:04] driver [Generic PHY] (irq=POLL)
[ 6.846751] mt7530 mdio-bus:1f: configuring for fixed/rgmii link mode
[ 6.863756] DSA: tree 0 setup
[ 6.870014] rt2880-pinmux pinctrl: pcie is already enabled
[ 6.881051] mt7621-pci 1e140000.pcie: host bridge /pcie@1e140000 ranges:
[ 6.894427] mt7621-pci 1e140000.pcie: No bus range found for /pcie@1e140000, using [bus 00-ff]
[ 6.911956] mt7621-pci 1e140000.pcie: MEM 0x0060000000..0x006fffffff -> 0x0000000000
[ 6.928265] mt7621-pci 1e140000.pcie: IO 0x001e160000..0x001e16ffff -> 0x0000000000
[ 6.944661] mt7621-pci-phy 1e149000.pcie-phy: PHY for 0xbe149000 (dual port = 1)
[ 6.959804] mt7621-pci-phy 1e14a000.pcie-phy: PHY for 0xbe14a000 (dual port = 0)
[ 6.974856] mt7621-pci 1e140000.pcie: failed to parse bus ranges property: -22
[ 7.089504] mt7621-pci-phy 1e149000.pcie-phy: Xtal is 40MHz
[ 7.100626] mt7621-pci-phy 1e14a000.pcie-phy: Xtal is 40MHz
[ 7.211956] mt7621-pci 1e140000.pcie: pcie2 no card, disable it (RST & CLK)
[ 7.225839] mt7621-pci 1e140000.pcie: PCIE0 enabled
[ 7.235559] mt7621-pci 1e140000.pcie: PCIE1 enabled
[ 7.245279] mt7621-pci 1e140000.pcie: PCI coherence region base: 0x60000000, mask/settings: 0xf0000002
[ 7.264005] mt7621-pci 1e140000.pcie: PCI host bridge to bus 0000:00
[ 7.276701] pci_bus 0000:00: root bus resource [io 0x1e160000-0x1e16ffff]
[ 7.290409] pci_bus 0000:00: root bus resource [mem 0x60000000-0x6fffffff]
[ 7.304113] pci_bus 0000:00: root bus resource [bus 00-ff]
[ 7.315057] pci_bus 0000:00: root bus resource [mem 0x60000000-0x6fffffff] (bus address [0x00000000-0x0fffffff])
[ 7.335371] pci 0000:00:00.0: [0e8d:0801] type 01 class 0x060400
[ 7.347367] pci 0000:00:00.0: reg 0x10: [mem 0x00000000-0x7fffffff]
[ 7.359854] pci 0000:00:00.0: reg 0x14: initial BAR value 0x00000000 invalid
[ 7.373897] pci 0000:00:00.0: reg 0x14: [mem size 0x00010000]
[ 7.385418] pci 0000:00:00.0: supports D1
[ 7.393407] pci 0000:00:00.0: PME# supported from D0 D1 D3hot
[ 7.405623] pci 0000:00:01.0: [0e8d:0801] type 01 class 0x060400
[ 7.417638] pci 0000:00:01.0: reg 0x10: [mem 0x00000000-0x7fffffff]
[ 7.430139] pci 0000:00:01.0: reg 0x14: initial BAR value 0x00000000 invalid
[ 7.444181] pci 0000:00:01.0: reg 0x14: [mem size 0x00010000]
[ 7.455690] pci 0000:00:01.0: supports D1
[ 7.463688] pci 0000:00:01.0: PME# supported from D0 D1 D3hot
[ 7.476742] pci 0000:00:00.0: bridge configuration invalid ([bus 00-00]), reconfiguring
[ 7.492719] pci 0000:00:01.0: bridge configuration invalid ([bus 00-00]), reconfiguring
[ 7.508934] pci 0000:01:00.0: [14c3:7603] type 00 class 0x028000
[ 7.520951] pci 0000:01:00.0: reg 0x10: initial BAR value 0x00000000 invalid
[ 7.535021] pci 0000:01:00.0: reg 0x10: [mem size 0x00100000]
[ 7.546607] pci 0000:01:00.0: PME# supported from D0 D3hot D3cold
[ 7.560394] pci 0000:00:00.0: PCI bridge to [bus 01-ff]
[ 7.570844] pci 0000:00:00.0: bridge window [io 0x0000-0x0fff]
[ 7.582987] pci 0000:00:00.0: bridge window [mem 0x60000000-0x600fffff]
[ 7.596526] pci 0000:00:00.0: bridge window [mem 0x60000000-0x600fffff pref]
[ 7.610916] pci_bus 0000:01: busn_res: [bus 01-ff] end is updated to 01
[ 7.624349] pci 0000:02:00.0: [14c3:7615] type 00 class 0x000280
[ 7.636381] pci 0000:02:00.0: reg 0x10: initial BAR value 0x00000000 invalid
[ 7.650436] pci 0000:02:00.0: reg 0x10: [mem size 0x00100000 64bit]
[ 7.663100] pci 0000:02:00.0: 2.000 Gb/s available PCIe bandwidth, limited by 2.5 GT/s PCIe x1 link at 0000:00:01.0 (capable of 4.000 Gb/s with 5.0 GT/s PCIe x1 link)
[ 7.693958] pci 0000:00:01.0: PCI bridge to [bus 02-ff]
[ 7.704402] pci 0000:00:01.0: bridge window [io 0x0000-0x0fff]
[ 7.716541] pci 0000:00:01.0: bridge window [mem 0x60000000-0x600fffff]
[ 7.730080] pci 0000:00:01.0: bridge window [mem 0x60000000-0x600fffff pref]
[ 7.744478] pci_bus 0000:02: busn_res: [bus 02-ff] end is updated to 02
[ 7.757716] pci 0000:00:00.0: BAR 0: no space for [mem size 0x80000000]
[ 7.770890] pci 0000:00:00.0: BAR 0: failed to assign [mem size 0x80000000]
[ 7.784775] pci 0000:00:01.0: BAR 0: no space for [mem size 0x80000000]
[ 7.797954] pci 0000:00:01.0: BAR 0: failed to assign [mem size 0x80000000]
[ 7.811823] pci 0000:00:00.0: BAR 8: assigned [mem 0x60000000-0x600fffff]
[ 7.825353] pci 0000:00:00.0: BAR 9: assigned [mem 0x60100000-0x601fffff pref]
[ 7.839745] pci 0000:00:01.0: BAR 8: assigned [mem 0x60200000-0x602fffff]
[ 7.853280] pci 0000:00:01.0: BAR 9: assigned [mem 0x60300000-0x603fffff pref]
[ 7.867684] pci 0000:00:00.0: BAR 1: assigned [mem 0x60400000-0x6040ffff]
[ 7.881214] pci 0000:00:01.0: BAR 1: assigned [mem 0x60410000-0x6041ffff]
[ 7.894745] pci 0000:00:00.0: BAR 7: assigned [io 0x1e160000-0x1e160fff]
[ 7.908275] pci 0000:00:01.0: BAR 7: assigned [io 0x1e161000-0x1e161fff]
[ 7.921811] pci 0000:01:00.0: BAR 0: assigned [mem 0x60000000-0x600fffff]
[ 7.935341] pci 0000:00:00.0: PCI bridge to [bus 01]
[ 7.945238] pci 0000:00:00.0: bridge window [io 0x1e160000-0x1e160fff]
[ 7.958759] pci 0000:00:00.0: bridge window [mem 0x60000000-0x600fffff]
[ 7.972300] pci 0000:00:00.0: bridge window [mem 0x60100000-0x601fffff pref]
[ 7.986706] pci 0000:02:00.0: BAR 0: assigned [mem 0x60200000-0x602fffff 64bit]
[ 8.001273] pci 0000:00:01.0: PCI bridge to [bus 02]
[ 8.011169] pci 0000:00:01.0: bridge window [io 0x1e161000-0x1e161fff]
[ 8.024694] pci 0000:00:01.0: bridge window [mem 0x60200000-0x602fffff]
[ 8.038228] pci 0000:00:01.0: bridge window [mem 0x60300000-0x603fffff pref]
[ 8.072056] Freeing unused kernel memory: 4916K
[ 8.081153] This architecture does not have kernel memory protection.
[ 8.094020] Run /init as init process
[ 8.101684] mt7530 mdio-bus:1f: Link is Up - 1Gbps/Full - flow control off
[ 8.596860] init: Console is alive
[ 8.605068] init: - watchdog -
[ 8.625631] kmodloader: loading kernel modules from /etc/modules-boot.d/*
[ 8.650014] usbcore: registered new interface driver usbfs
[ 8.661160] usbcore: registered new interface driver hub
[ 8.671981] usbcore: registered new device driver usb
[ 8.692645] xhci-mtk 1e1c0000.xhci: supply vbus not found, using dummy regulator
[ 8.707675] xhci-mtk 1e1c0000.xhci: supply vusb33 not found, using dummy regulator
[ 8.723026] xhci-mtk 1e1c0000.xhci: xHCI Host Controller
[ 8.733654] xhci-mtk 1e1c0000.xhci: new USB bus registered, assigned bus number 1
[ 8.762396] xhci-mtk 1e1c0000.xhci: hcc params 0x01401198 hci version 0x96 quirks 0x0000000000290010
[ 8.780696] xhci-mtk 1e1c0000.xhci: irq 20, io mem 0x1e1c0000
[ 8.793222] hub 1-0:1.0: USB hub found
[ 8.800797] hub 1-0:1.0: 2 ports detected
[ 8.809393] xhci-mtk 1e1c0000.xhci: xHCI Host Controller
[ 8.820039] xhci-mtk 1e1c0000.xhci: new USB bus registered, assigned bus number 2
[ 8.834975] xhci-mtk 1e1c0000.xhci: Host supports USB 3.0 SuperSpeed
[ 8.847844] usb usb2: We don't know the algorithms for LPM for this host, disabling LPM.
[ 8.864779] hub 2-0:1.0: USB hub found
[ 8.872370] hub 2-0:1.0: 1 port detected
[ 8.887452] kmodloader: done loading kernel modules from /etc/modules-boot.d/*
[ 8.922613] init: - preinit -
[ 9.127305] random: jshn: uninitialized urandom read (4 bytes read)
[ 9.185390] random: jshn: uninitialized urandom read (4 bytes read)
[ 9.215475] random: jshn: uninitialized urandom read (4 bytes read)
[ 9.595952] mtk_soc_eth 1e100000.ethernet eth0: configuring for fixed/rgmii link mode
[ 9.612087] mtk_soc_eth 1e100000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx/tx
[ 9.612749] mt7530 mdio-bus:1f lan1: configuring for phy/gmii link mode
[ 9.642439] 8021q: adding VLAN 0 to HW filter on device lan1
[ 9.656367] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready
Press the [f] key and hit [enter] to enter failsafe mode
Press the [1], [2], [3] or [4] key and hit [enter] to select the debug level
[ 12.773132] mt7530 mdio-bus:1f lan1: Link is Up - 1Gbps/Full - flow control rx/tx
[ 12.788107] IPv6: ADDRCONF(NETDEV_CHANGE): lan1: link becomes ready
[ 13.798181] mt7530 mdio-bus:1f lan1: Link is Down
[ 13.816879] procd: - early -
[ 13.822918] procd: - watchdog -
[ 14.392444] procd: - watchdog -
[ 14.399162] procd: - ubus -
[ 14.466429] procd: - init -
Please press Enter to activate this console.
[ 14.825356] kmodloader: loading kernel modules from /etc/modules.d/*
[ 15.012789] urngd: v1.0.2 started.
[ 15.040060] Loading modules backported from Linux version v5.15.8-0-g43e577d7a2cb
[ 15.055059] Backport generated by backports.git v5.15.8-1-0-g83f664bb
[ 15.089150] xt_time: kernel timezone is -0000
[ 15.154432] mt7621-pci 1e140000.pcie: bus=2 slot=1 irq=23
[ 15.165338] pci 0000:00:01.0: enabling device (0004 -> 0007)
[ 15.176746] mt7615e 0000:02:00.0: enabling device (0000 -> 0002)
[ 15.190372] mt7615e 0000:02:00.0: Invalid MAC address, using random address a2:32:d6:1f:e1:e0
[ 15.204131] random: crng init done
[ 15.214199] random: 7 urandom warning(s) missed due to ratelimiting
[ 15.243016] mt7615e 0000:02:00.0: HW/SW Version: 0x8a108a10, Build Time: 20180518100604a
[ 15.243016]
[ 15.244938] PPP generic driver version 2.4.2
[ 15.272637] NET: Registered protocol family 24
[ 15.287007] mt7615e 0000:02:00.0: N9 Firmware Version: _reserved_, Build Time: 20200814163649
[ 15.301225] kmodloader: done loading kernel modules from /etc/modules.d/*
[ 15.326266] mt7615e 0000:02:00.0: CR4 Firmware Version: _reserved_, Build Time: 20190121161307
BusyBox v1.35.0 (2022-01-12 20:14:29 UTC) built-in shell (ash)
_______ ________ __
| |.-----.-----.-----.| | | |.----.| |_
| - || _ | -__| || | | || _|| _|
|_______|| __|_____|__|__||________||__| |____|
|__| W I R E L E S S F R E E D O M
-----------------------------------------------------
OpenWrt SNAPSHOT, r18541+1-7f2052ef22
-----------------------------------------------------
=== WARNING! =====================================
There is no root password defined on this device!
Use the "passwd" command to set up a new password
in order to prevent unauthorized SSH logins.
--------------------------------------------------
root@OpenWrt:/# [ 32.305525] mtk_soc_eth 1e100000.ethernet eth0: Link is Down
[ 32.326750] mtk_soc_eth 1e100000.ethernet eth0: configuring for fixed/rgmii link mode
[ 32.342762] mtk_soc_eth 1e100000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx/tx
[ 32.355461] mt7530 mdio-bus:1f lan1: configuring for phy/gmii link mode
[ 32.373314] 8021q: adding VLAN 0 to HW filter on device lan1
[ 32.388289] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready
[ 32.401904] br-lan: port 1(lan1) entered blocking state
[ 32.412445] br-lan: port 1(lan1) entered disabled state
[ 32.423804] device lan1 entered promiscuous mode
[ 32.433210] device eth0 entered promiscuous mode
[ 32.467836] mt7530 mdio-bus:1f lan2: configuring for phy/gmii link mode
[ 32.481619] 8021q: adding VLAN 0 to HW filter on device lan2
[ 32.496337] br-lan: port 2(lan2) entered blocking state
[ 32.506862] br-lan: port 2(lan2) entered disabled state
[ 32.518245] device lan2 entered promiscuous mode
[ 32.540972] mt7530 mdio-bus:1f lan3: configuring for phy/gmii link mode
[ 32.554732] 8021q: adding VLAN 0 to HW filter on device lan3
[ 32.569456] br-lan: port 3(lan3) entered blocking state
[ 32.580221] br-lan: port 3(lan3) entered disabled state
[ 32.592084] device lan3 entered promiscuous mode
[ 32.613318] mt7530 mdio-bus:1f lan4: configuring for phy/gmii link mode
[ 32.627239] 8021q: adding VLAN 0 to HW filter on device lan4
[ 32.643002] br-lan: port 4(lan4) entered blocking state
[ 32.653587] br-lan: port 4(lan4) entered disabled state
[ 32.665780] device lan4 entered promiscuous mode
[ 32.694479] mt7530 mdio-bus:1f wan: configuring for phy/gmii link mode
[ 32.708169] 8021q: adding VLAN 0 to HW filter on device wan
[ 34.693001] mt7530 mdio-bus:1f lan4: Link is Up - 100Mbps/Full - flow control rx/tx
[ 34.708330] br-lan: port 4(lan4) entered blocking state
[ 34.718761] br-lan: port 4(lan4) entered forwarding state
[ 34.731091] IPv6: ADDRCONF(NETDEV_CHANGE): br-lan: link becomes ready
[ 35.493124] mt7530 mdio-bus:1f lan1: Link is Up - 1Gbps/Full - flow control rx/tx
[ 35.508109] br-lan: port 1(lan1) entered blocking state
[ 35.518539] br-lan: port 1(lan1) entered forwarding state
[ 36.853020] mt7530 mdio-bus:1f wan: Link is Up - 1Gbps/Full - flow control off
[ 36.867480] IPv6: ADDRCONF(NETDEV_CHANGE): wan: link becomes ready
[ 56.612548] mt7530 mdio-bus:1f wan: Link is Down
[ 59.733005] mt7530 mdio-bus:1f wan: Link is Up - 1Gbps/Full - flow control off
[ 64.612551] mt7530 mdio-bus:1f lan1: Link is Down
[ 64.622041] br-lan: port 1(lan1) entered disabled state
[ 73.973115] mt7530 mdio-bus:1f lan1: Link is Up - 1Gbps/Full - flow control rx/tx
[ 73.988099] br-lan: port 1(lan1) entered blocking state
[ 73.998530] br-lan: port 1(lan1) entered forwarding state
[ 138.692537] mt7530 mdio-bus:1f lan4: Link is Down
[ 138.702369] br-lan: port 4(lan4) entered disabled state
[ 145.972992] mt7530 mdio-bus:1f lan4: Link is Up - 100Mbps/Full - flow control rx/tx
[ 145.988326] br-lan: port 4(lan4) entered blocking state
[ 145.998763] br-lan: port 4(lan4) entered forwarding state
