Xiaomi Router 3 Pro. 5 GHz channels are not switched.

5 GHz channels are not switched.
Channel 36 only.
If switch above channel 40, 5GHz interface stops working.
Tested on versions 19.07 and 21.02.
Is it just me or is it global?

Keep in mind that your router needs to passively listen for radar events for at least 60s, before it is allowed to use a DFS channel. Make sure to wait ling enough, before declaring it broken.





The 5 GHz interface GENERALLY stops working.
When I return to channel 36, everything is ok.

+1 here having the same problem

Tue Dec  7 00:18:06 2021 daemon.notice hostapd: Configuration file: /var/run/hostapd-phy1.conf (phy wlan1) --> new PHY
Tue Dec  7 00:18:06 2021 kern.info kernel: [104891.282208] br-lan: port 5(wlan1) entered blocking state
Tue Dec  7 00:18:06 2021 kern.info kernel: [104891.287897] br-lan: port 5(wlan1) entered disabled state
Tue Dec  7 00:18:06 2021 kern.info kernel: [104891.294251] device wlan1 entered promiscuous mode
Tue Dec  7 00:18:06 2021 daemon.notice hostapd: Frequency 5300 (primary) not allowed for AP mode, flags: 0x217b NO-IR RADAR
Tue Dec  7 00:18:06 2021 daemon.err hostapd: Primary frequency not allowed
Tue Dec  7 00:18:06 2021 daemon.warn hostapd: wlan1: IEEE 802.11 Configured channel (60) or frequency (5300) not found from the channel list of the current mode (2) IEEE 802.11a
Tue Dec  7 00:18:06 2021 daemon.warn hostapd: wlan1: IEEE 802.11 Hardware does not support configured channel
Tue Dec  7 00:18:06 2021 daemon.err hostapd: Could not select hw_mode and channel. (-3)
Tue Dec  7 00:18:06 2021 daemon.notice hostapd: wlan1: interface state UNINITIALIZED->DISABLED
Tue Dec  7 00:18:06 2021 daemon.notice hostapd: wlan1: AP-DISABLED
Tue Dec  7 00:18:06 2021 daemon.err hostapd: wlan1: Unable to setup interface.
Tue Dec  7 00:18:06 2021 daemon.notice hostapd: nl80211: deinit ifname=wlan1 disabled_11b_rates=0
Tue Dec  7 00:18:06 2021 kern.info kernel: [104891.325271] device wlan1 left promiscuous mode
Tue Dec  7 00:18:06 2021 kern.info kernel: [104891.330611] br-lan: port 5(wlan1) entered disabled state
Tue Dec  7 00:18:06 2021 daemon.notice hostapd: wlan1: CTRL-EVENT-TERMINATING
Tue Dec  7 00:18:06 2021 daemon.err hostapd: hostapd_free_hapd_data: Interface wlan1 wasn't started
Tue Dec  7 00:18:06 2021 daemon.notice netifd: radio1 (27893): Command failed: Invalid argument
Tue Dec  7 00:18:06 2021 daemon.notice netifd: radio1 (27893): Device setup failed: HOSTAPD_START_FAILED

Ok Let me answer my problem. Seems it didn't took long to find out. You need 1st to select the country you are living so the system will retrieve the "Allowed" 5G channels of your country. Seems they are called DFS bands and each country allows some of them for home usage.

Here you can have some info about it. https://www.lairdconnect.com/support/faqs/what-channels-are-supported-both-24-ghz-and-5ghz-band-most-countries.

Of course you can "trick" the country selection to open more channels but this means you go against your country laws.
