Dear OpenWrt Forum,
with the following issue I would like to reach out to you hoping someone has a hint for me.
Issue
I successfully flashed OpenWrt onto my Fritz!Box 7520 and have a synced VDSL connection. My issue is that with my current configuration I have no access to the internet.
Context
Currently I have a contract with 1&1 (Germany) and I get a public IPv4. Therefore I left out the paragraph in OpenWrt ISP Config for DS_Lite. (Also with my ISP Router every traceroute -A is within AS3320 = Deutsche Telekom).
service dsl_control dslstat excerpt
service dsl_control dslstat | grep 'state"\|mode"\|data_rate\|snr' | grep -v ra_mode
"state": "Showtime with TC-Layer sync",
"power_state": "L0 - Synchronized",
"mode": "G.993.2 (VDSL2, Profile 17a, with down- and upstream vectoring)",
"data_rate": 37000000,
"snr": 9.600000,
"data_rate": 79990000,
"snr": 10.000000,
ping and nslookup diagnostics (using ISP DNS for now)
nslookup openwrt.org
Server: 127.0.0.1
Address: 127.0.0.1:53
Non-authoritative answer:
Name: openwrt.org
Address: 64.226.122.113
Non-authoritative answer:
Name: openwrt.org
Address: 2a03:b0c0:3:d0::1a51:c001
ping -c 5 openwrt.org
PING openwrt.org (2a03:b0c0:3:d0::1a51:c001): 56 data bytes
--- openwrt.org ping statistics ---
5 packets transmitted, 0 packets received, 100% packet loss
ping -c 5 -4 openwrt.org
PING openwrt.org (64.226.122.113): 56 data bytes
--- openwrt.org ping statistics ---
5 packets transmitted, 0 packets received, 100% packet loss
Forum Search
I already did search for similar forum questions, but it seems they all have a different problems:
Issue with DSL modem/DSL
1
2
3
4
Issue with Supervectoring
5
Issue with ADSL
6
I would be glad if someone could provide a hint and hopefully I am not overlooking something completely stupid.
Thanks in advance,
Cheers Daniel
Config Details:
/etc/config/firewall
config defaults
option input 'REJECT'
option output 'ACCEPT'
option forward 'REJECT'
option synflood_protect '1'
config zone
option name 'lan'
list network 'lan'
option input 'ACCEPT'
option output 'ACCEPT'
option forward 'ACCEPT'
option mtu_fix '1'
config zone
option name 'wan'
list network 'wan'
list network 'wan6'
option input 'REJECT'
option output 'ACCEPT'
option forward 'REJECT'
option masq '1'
option mtu_fix '1'
config forwarding
option src 'lan'
option dest 'wan'
config rule
option name 'Allow-DHCP-Renew'
option src 'wan'
option proto 'udp'
option dest_port '68'
option target 'ACCEPT'
option family 'ipv4'
config rule
option name 'Allow-Ping'
option src 'wan'
option proto 'icmp'
option icmp_type 'echo-request'
option family 'ipv4'
option target 'ACCEPT'
config rule
option name 'Allow-IGMP'
option src 'wan'
option proto 'igmp'
option family 'ipv4'
option target 'ACCEPT'
config rule
option name 'Allow-DHCPv6'
option src 'wan'
option proto 'udp'
option dest_port '546'
option family 'ipv6'
option target 'ACCEPT'
config rule
option name 'Allow-MLD'
option src 'wan'
option proto 'icmp'
option src_ip 'fe80::/10'
list icmp_type '130/0'
list icmp_type '131/0'
list icmp_type '132/0'
list icmp_type '143/0'
option family 'ipv6'
option target 'ACCEPT'
config rule
option name 'Allow-ICMPv6-Input'
option src 'wan'
option proto 'icmp'
list icmp_type 'echo-request'
list icmp_type 'echo-reply'
list icmp_type 'destination-unreachable'
list icmp_type 'packet-too-big'
list icmp_type 'time-exceeded'
list icmp_type 'bad-header'
list icmp_type 'unknown-header-type'
list icmp_type 'router-solicitation'
list icmp_type 'neighbour-solicitation'
list icmp_type 'router-advertisement'
list icmp_type 'neighbour-advertisement'
option limit '1000/sec'
option family 'ipv6'
option target 'ACCEPT'
config rule
option name 'Allow-ICMPv6-Forward'
option src 'wan'
option dest '*'
option proto 'icmp'
list icmp_type 'echo-request'
list icmp_type 'echo-reply'
list icmp_type 'destination-unreachable'
list icmp_type 'packet-too-big'
list icmp_type 'time-exceeded'
list icmp_type 'bad-header'
list icmp_type 'unknown-header-type'
option limit '1000/sec'
option family 'ipv6'
option target 'ACCEPT'
config rule
option name 'Allow-IPSec-ESP'
option src 'wan'
option dest 'lan'
option proto 'esp'
option target 'ACCEPT'
config rule
option name 'Allow-ISAKMP'
option src 'wan'
option dest 'lan'
option dest_port '500'
option proto 'udp'
option target 'ACCEPT'
/etc/config/network
config interface 'loopback'
option device 'lo'
option proto 'static'
option ipaddr '127.0.0.1'
option netmask '255.0.0.0'
config globals 'globals'
option ula_prefix 'fd3e:cbe5:802c::/48'
config atm-bridge 'atm'
option vpi '1'
option vci '32'
option encaps 'llc'
option payload 'bridged'
option nameprefix 'dsl'
config dsl 'dsl'
option annex 'j'
option tone 'bv'
option ds_snr_offset '0'
option firmware '/lib/firmware/vdsl.bin'
config device
option name 'br-lan'
option type 'bridge'
list ports 'lan1'
list ports 'lan2'
list ports 'lan3'
list ports 'lan4'
config interface 'lan'
option device 'br-lan'
option proto 'static'
option ipaddr '192.168.2.1'
option netmask '255.255.255.0'
option ip6assign '60'
config device
option name 'dsl0'
option macaddr '1C:ED:6F:41:AE:38'
config interface 'wan'
option device 'dsl0.7'
option proto 'pppoe'
option username '1und1/<redacted>@online.de'
option password '<redacted>'
option ipv6 '1'
config interface 'wan6'
option device '@wan'
option proto 'dhcpv6'
config device
option type '8021ad'
option ifname 'dsl0'
option vid '7'
option name 'dsl0.7'
