Looking for 4G supporting B28

Hey,
I don't know how to look for the list of router that would support the band B28 (700mhz) ; the only one I found isn't supported by OpenWrt and is kind of pricey (MR600) ?

I think "I need" that band support because on the same SIM at the same location : a phone supporting B28 get 4G, while using the DWM-222 only get H+. Is my assumption right or could I be mistaken too ? (like maybe, the smartphone's antenna is just better than my g4 dongle ?)

The closest antenna from my location is that one (I'm about 2km of it, the operator is "Free") : https://www.cartoradio.fr/index.html#/cartographie/lonlat/-3.51886/47.89699

I hope I answered your questions...

[OpenWrt Wiki] Table of Hardware: LTE Modem supported

price:

https://www.amazon.fr/Zyxel-appareils-Déverrouillé-Configuration-LTE5398-M904/dp/B0B6W9CXZT/ref=sr_1_1_sspa?__mk_fr_FR=ÅMÅŽÕÑ&crid=WNBR5O4ZRFK9&keywords=ZyXEL%2BLTE5398-M904&qid=1702156073&sprefix=zyxel%2Blte5398-m904%2B%2Caps%2C151&sr=8-1-spons&sp_csd=d2lkZ2V0TmFtZT1zcF9hdGY&th=1

1 Like

Before purchasing any router I recommend checking with your smartphone which frequencies/bands are present in your area (obviously if the smartphone is recent enough to support a large number of frequencies/bands)

The friend's smartphone won't allow it, they disabled playstore and only uses f-froid, guess I'll try my chances T_T

EDIT : scratch that, found an APK. Indeed my assumption that the Free operator uses only the 700Mhz band over my place is confirmed !

One last question : the category. The reception isn't great here. Will it do any good if I pick a category 4 or 6 ? (it's almost twice as pricey to jump from one the another) https://en.wikipedia.org/wiki/LTE_Advanced

ZTE MF286D ?

Usually cheap, if it supports the bands you need, and you can find a used one.

1 Like

I see mr600 for about the same price used but almost sure there s no openwrt support for it

MR600v2 is supported.

The ZTE is however cat 12, and you'll get 250 mbit or more out of it.

The higher the cat the best of course, but... Isn't it more a thing of people being well serviced to begin with ?

I couldn't find anything about "getting more from a flimsy coverage" but by adding an external antenna.

Sure, the better coverage the higher speed.

Or an external antenna like on the roof would dramatically improve signal/speed (hopefully not much out of topic for OP)

...And then comes the scary message you find about somehow unfortunate router/antennas pairs :face_holding_back_tears:

I wish there were less choices to pick from at this point, or that I could just test things before buying them. It's scary how much time you can lose browsing the "internet mall" T_T

What @otyugh said.

The ZTE supports two external antennas, no idea about the MR600.

In a weak signal area, a purpose-built outdoor CPE is advisable rather than cobbling something together with external antennas. The Zyxel NR7101 was popular here for a while as a large number of them had dropped onto the used market after a service company went bankrupt. Now though they seem to have become expensive.

1 Like

If you strip the ZTE down to the PCB it supports 5 external antennas.

I l can vouch for the NR7101 running OpenWrt. Mine has been solid with excellent signal stats to line of sight cell tower, although I did have to RMA it recently in its second year as it randomly stopped powering on. The Zyxel two year warranty proved helpful and their RMA process was very quick and efficient. Batch of units have bad internal PoE module apparently. Think I was just very unlucky. Price dropped in the UK from ÂŁ700 to ÂŁ400.

Before that I used Huwaei B818-263 in bridge mode, and I can also recommend that for an indoor device, albeit no OpenWrt.

problem is, it's 10x the price of the ZTE, where I live.

I can easily get my hands on an used 286D for 30€, but it's tricky to find the NR7101 below 300€, I managed to snag a new one for 270€, but I got lucky.

3 Likes

Can't find less than 60€ here, but its in my prize range. I'll put some alarm here and there if I can get a bargain. Worth testing, 300€ is too steep personally (psychologically at least, I may be wrong not to invest that one time).
