Help Entering Recovery Mode on Arcadyan VRV9510KWAC23 (livebox next)

Installing and Using OpenWrt
22

@nicefile @Kifixo
in the installation process in wiki the u-boot.ltq.lzo.nandsplfile size after begin transferred is 346 KB.
Filename 'u-boot.ltq.lzo.nandspl'. Load address: 0x81000000 Loading: ######################### done Bytes transferred =354728 (569a8 hex)

but the file on https://github.com/danielhuici/arcadyan-vrv9510kwac23-utils/tree/main
is 1024 KB. is it the same file you used because there sizes are different ?

Filename 'u-boot.ltq.lzo.nandspl'. Load address: 0x81000000 Loading: ################################################################# ####### 2.6 MiB/s done Bytes transferred = 1048576 (100000 hex)

is this difference normal ?? btw the md5 as correct as stated in the wiki c1e92ac27ff996406a5ece4641119dbd

23

tried with older files same issue :melting_face:

24

@Kifixo im getting another router , maybe this 2017 model has a different hardware or smthn

545547812_1279439293655691_3254889026300415814_n
545547812_1279439293655691_3254889026300415814_n2048×946 207 KB

547142920_1703060210389325_630194278199109347_n
547142920_1703060210389325_630194278199109347_n946×2048 176 KB

547298590_1298976038586079_8830775077754650863_n
547298590_1298976038586079_8830775077754650863_n946×2048 191 KB

545772761_4091684131072724_8598615176560040622_n
545772761_4091684131072724_8598615176560040622_n2048×946 175 KB

25

i found these older revision which one should it take

26

issue was unsupported FW version 00.96.607B only 00.96.601J and 00.96.607J Tested working

27

You had to downgrade the stock fw ?

28

no i got another device

29

unsupported FW version 00.96.607B only 00.96.601J and 00.96.607J Tested working

30

Thnx, should probably go into the wiki.

31

i’ll do it have also firmware to edit 00.96.607B into 00.96.601J but it need the whole nand to be put in a nand flasher but i’ll put it anyway who knows

32

+the latest initamfs snapshot dosen’t have luci if someone who isn’t familiar with these get 192.168.1.1 refused to connect error he’ll think that the installation has failed it’s better to link latest stable release instead

33

Please fill in documentation section so that wiki is completed....

34

Does snapshots ever have Luci ?

35

is there any blank wiki to test before putting in official ?

36

Just add a link to wiki page and explain what you want changed or even better write your paragraph....
