Just make sure I got this right, to go back to vendor firmware all I need to do is run "sysupgrade -F /tmp/FW_RT3200_1.0.01.101415_prod.img" right? I'm using Belkin but that command should work with Linksys as well.
Did you read the UBI installer readme?
Especially this part:
WARNING This will replace the bootloader (TF-A 2.2, U-Boot 2020.10) and convert the flash layout of the device to UBI! The installer stores a copy of the previous bootchain in a dedicated UBI volume
boot_backup. If you want to go back to the vendor firmware, you will have to boot into recovery mode (ie. initramfs), copy those files into/tmp, umount the UBI volume, detach the UBI device and then write the files to the corresponding MTD partitions (mtd write $file /dev/mtdX).
Hello,
Today I flashed my RT3200 with the UBI version and the latest firmware:
But I can't configure 5GHz WiFi, is missing!
root@OpenWrt:~# iwinfo
wlan0 ESSID: unknown
Access Point: C4:41:1E:F8:1E:C7
Mode: Client Channel: unknown (unknown)
Center Channel 1: unknown 2: unknown
Tx-Power: 6 dBm Link Quality: unknown/70
Signal: unknown Noise: unknown
Bit Rate: unknown
Encryption: unknown
Type: nl80211 HW Mode(s): 802.11bgn
Hardware: 14C3:7622 14C3:7622 [MediaTek MT7622]
TX power offset: none
Frequency offset: none
Supports VAPs: yes PHY name: phy0
root@OpenWrt:~# cat /etc/config/wireless
config wifi-device 'radio0'
option type 'mac80211'
option channel '11'
option hwmode '11g'
option path 'platform/18000000.wmac'
option htmode 'HT20'
option disabled '1'
config wifi-iface 'default_radio0'
option device 'radio0'
option network 'lan'
option mode 'ap'
option ssid 'OpenWrt'
option encryption 'none'
Maybe I forgotten a step... can anyone help me?
Thanks!
try upgrade the last snapshot wit hback up flash firmware and sysupgrade ubi .itb
1 Like
Sounds like you have possibly not yet installed the actual firmware, and are still running the recovery image...
I had similar condition after flashing my RT3200 with the UBI install image. Things normalised once I had then used sysupgrade to install the ubi-squashfs-sysupgrade.itb, like Dopam-IT_1987 suggested
You chould check from console with "df", if you have normal overlay etc., or are you just running tmpfs (with the recovery initramfs image).
1 Like
How often should one be running auc? Every time the kernel changes? I'm coming from a Linux distro that tracks all CVEs for the packages installed and can recommend updates based on that - is there any equivalent for OpenWRT users to follow?
I dont use auc i use via web gui luci backup flash firmware
And i flash a new upgrade via flash firmware update in down with ubi.sysupgrade.itb snapshot
My understanding is that auc pulls the sysupgrade image.
My question is how often should I be updating a router on SNAPSHOT?
How do I balance "stability" (since we have no stable builds) vs. security?
That's a personal 'policy' decision.
- one approach would be to closely follow the commits entering master and making an informed decision based on that.
- another one would be to find a workable personal cadence, in the line of every weekend, twice a month, monthly, every three months - roughly matching the pace of minor updates of the stable branch.
There are many options between these extremes.
2 Likes
Yes you're right can you send a link of commits please ?
1 Like
Yes but I was talking about non UBI version. I flashed snapshot and coud not install LuCI due to some package format issues. I eventually used the power-off trick to swap boot partition and installed the vendor firmware.
I installed the non-UBI version as per your instructions. It worked as you mentioned. However, all the configurations got wiped off after reboot. Is this normal?
Disclaimer: I don't own this device, nor read the instructions in detail.
This behaviour sounds as if you flashed an initramfs image, without completing the process by then flashing the sysupgrade image.
I flashed this file https://downloads.openwrt.org/snapshots/targets/mediatek/mt7622/openwrt-mediatek-mt7622-linksys_e8450-squashfs-sysupgrade.bin
This is the output of df command
root@OpenWrt:~# df
Filesystem 1K-blocks Used Available Use% Mounted on
/dev/root 4608 4608 0 100% /rom
tmpfs 247032 1068 245964 0% /tmp
tmpfs 247032 1532 245500 1% /tmp/root
overlayfs:/tmp/root 247032 1532 245500 1% /
tmpfs 512 0 512 0% /dev
I am assuming everything is getting stored in temp. How do I make this permanent? I am on the non-UBI version and on the 1st partition there is stock firmware. I also used the Openwrt image builder to add luci.
Apologies, I must confess that I jumped boat shortly after confirming that OpenWrt was working fine with that router (i.e. I have now switched to the UBI layout).
Consequently, I am no longer in position to confirm the behavior of the non-UBI variant.
I do not think I observed the behavior you described, but I may be misremembering, as my exposure to the non-UBI layout was short.
No worries. I will move to UBI if all works well. I am only scared if things break in the future it will be really difficult to go back to stock.
I was able to resolve this issue by reflashing the openwrt-mediatek-mt7622-linksys_e8450-squashfs-sysupgrade.bin image in Luci. Now the output of df command is as follows.
root@OpenWrt:~# df
Filesystem 1K-blocks Used Available Use% Mounted on
/dev/root 4608 4608 0 100% /rom
tmpfs 247032 348 246684 0% /tmp
/dev/mtdblock11 22272 2224 20048 10% /overlay
overlayfs:/overlay 22272 2224 20048 10% /
tmpfs 512 0 512 0% /dev
I'm using the router with latest snapshot but the MediaTek MT7622 802.11bgn device dies every couple of days. I have to reboot the router to make it work again. Anyone aware of the issues? @daniel ?
I've been using the Belkin RT3200 version of this router for about two weeks now with a snapshot image. So far I'm really impressed, it's been stable, reliable and fast enough for me. The only thing I just noticed when SSHing in is that the CPU scaling governor is currently set to "userspace". As a result, scaling_cur_freq always reads 1.35GHz. Looks like this is chosen by the default 5.10 kernel config for mt7622:
CONFIG_CPU_FREQ_DEFAULT_GOV_USERSPACE=y
In the interest of preserving power, I just set the governor to ondemand. After doing so, it seems to clock all the way back to 30MHz when it's idle. When I do e.g. a speed test, it comes up to ~800MHz while it doesn't stutter on Wifi throughput. In other words, that seems to work fine for me. I'll leave it running like this for a few days to see if it impacts stability, and I'll plunck it into rc.local, but it does beg the question: isn't the ondemand governor (or perhaps schedutil) a better default option for OpenWRT?
6 Likes
