but BPI-R3 have 6ghz support and ax6000 no, is that true?
@anon4457646 Where can I check if it has 6Ghz support or not? I have both of them running now.
A quick check on Wifi settings, both of them are up to 165CH (5825Mhz) only.
iw phy0 info
or
iw phy1 info
Bananapi-BPI-R3
root@OpenWrt-Bananapi-BPI-R3:/# iw phy0 info
Wiphy phy0
wiphy index: 0
max # scan SSIDs: 4
max scan IEs length: 2200 bytes
max # sched scan SSIDs: 0
max # match sets: 0
Retry short limit: 7
Retry long limit: 4
Coverage class: 0 (up to 0m)
Device supports AP-side u-APSD.
Device supports T-DLS.
Available Antennas: TX 0xf RX 0xf
Configured Antennas: TX 0xf RX 0xf
Supported interface modes:
* IBSS
* managed
* AP
* AP/VLAN
* monitor
* mesh point
* P2P-client
* P2P-GO
Band 1:
Capabilities: 0x9ff
RX LDPC
HT20/HT40
SM Power Save disabled
RX Greenfield
RX HT20 SGI
RX HT40 SGI
TX STBC
RX STBC 1-stream
Max AMSDU length: 7935 bytes
No DSSS/CCK HT40
Maximum RX AMPDU length 65535 bytes (exponent: 0x003)
Minimum RX AMPDU time spacing: 4 usec (0x05)
HT TX/RX MCS rate indexes supported: 0-31
HE Iftypes: managed
HE MAC Capabilities (0x08011a000040):
+HTC HE Supported
Trigger Frame MAC Padding Duration: 2
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x2270ce126d00f3164e3f00):
HE40/2.4GHz
242 tone RUs/2.4GHz
Device Class: 1
LDPC Coding in Payload
HE SU PPDU with 1x HE-LTF and 0.8us GI
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformee
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered CQI Feedback
Partial Bandwidth Extended Range
Partial Bandwidth DL MU-MIMO
PPE Threshold Present
Power Boost Factor ar
HE SU PPDU & HE PPDU 4x HE-LTF 0.8us GI
Max NC: 2
20MHz in 40MHz HE PPDU 2.4GHz
20MHz in 160/80+80MHz HE PPDU
80MHz in 160/80+80MHz HE PPDU
DCM Max BW: 1
Longer Than 16HE SIG-B OFDM Symbols
Non-Triggered CQI Feedback
TX 1024-QAM
RX 1024-QAM
RX Full BW SU Using HE MU PPDU with Compression SIGB
RX Full BW SU Using HE MU PPDU with Non-Compression SIGB
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
PPE Threshold 0x3b 0x1c 0xc7 0x71 0x1c 0xc7 0x71 0x1c 0xc7 0x71
EHT Iftypes: managed
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: AP
HE MAC Capabilities (0x00051a081044):
+HTC HE Supported
TWT Responder
BSR
OM Control
Maximum A-MPDU Length Exponent: 3
BQR
A-MSDU in A-MPDU
OM Control UL MU Data Disable RX
HE PHY Capabilities: (0x0220ce926f1bafd0000c00):
HE40/2.4GHz
LDPC Coding in Payload
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformer
SU Beamformee
MU Beamformer
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Sounding Dimensions <= 80Mhz: 3
Sounding Dimensions > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered SU Beamforming Feedback
Triggered MU Beamforming Feedback
Partial Bandwidth Extended Range
PPE Threshold Present
Max NC: 2
STBC Tx > 80MHz
STBC Rx > 80MHz
TX 1024-QAM
RX 1024-QAM
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
PPE Threshold 0x3b 0x1c 0xc7 0x71 0x1c 0xc7 0x71 0x1c 0xc7 0x71
EHT Iftypes: AP
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: mesh point
HE MAC Capabilities (0x00011a000040):
+HTC HE Supported
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x02200c0000000000008000):
HE40/2.4GHz
LDPC Coding in Payload
STBC Tx <= 80MHz
STBC Rx <= 80MHz
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: mesh point
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
Frequencies:
* 2412 MHz [1] (29.0 dBm)
* 2417 MHz [2] (29.0 dBm)
* 2422 MHz [3] (29.0 dBm)
* 2427 MHz [4] (29.0 dBm)
* 2432 MHz [5] (29.0 dBm)
* 2437 MHz [6] (29.0 dBm)
* 2442 MHz [7] (29.0 dBm)
* 2447 MHz [8] (29.0 dBm)
* 2452 MHz [9] (29.0 dBm)
* 2457 MHz [10] (29.0 dBm)
* 2462 MHz [11] (29.0 dBm)
* 2467 MHz [12] (29.0 dBm)
* 2472 MHz [13] (29.0 dBm)
* 2484 MHz [14] (disabled)
valid interface combinations:
* #{ IBSS } <= 1, #{ AP, mesh point } <= 16, #{ managed } <= 19,
total <= 19, #channels <= 1, STA/AP BI must match, radar detect widths: { 20 MHz (no HT), 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz }
HT Capability overrides:
* MCS: ff ff ff ff ff ff ff ff ff ff
* maximum A-MSDU length
* supported channel width
* short GI for 40 MHz
* max A-MPDU length exponent
* min MPDU start spacing
max # scan plans: 1
max scan plan interval: -1
max scan plan iterations: 0
Supported extended features:
* [ VHT_IBSS ]: VHT-IBSS
* [ RRM ]: RRM
* [ BEACON_RATE_LEGACY ]: legacy beacon rate setting
* [ BEACON_RATE_HT ]: HT beacon rate setting
* [ BEACON_RATE_VHT ]: VHT beacon rate setting
* [ FILS_STA ]: STA FILS (Fast Initial Link Setup)
* [ CQM_RSSI_LIST ]: multiple CQM_RSSI_THOLD records
* [ CONTROL_PORT_OVER_NL80211 ]: control port over nl80211
* [ ACK_SIGNAL_SUPPORT ]: ack signal level support
* [ TXQS ]: FQ-CoDel-enabled intermediate TXQs
* [ SCAN_RANDOM_SN ]: use random sequence numbers in scans
* [ SCAN_MIN_PREQ_CONTENT ]: use probe request with only rate IEs in scans
* [ AIRTIME_FAIRNESS ]: airtime fairness scheduling
* [ AQL ]: Airtime Queue Limits (AQL)
* [ CONTROL_PORT_NO_PREAUTH ]: disable pre-auth over nl80211 control port support
* [ DEL_IBSS_STA ]: deletion of IBSS station support
* [ SCAN_FREQ_KHZ ]: scan on kHz frequency support
* [ CONTROL_PORT_OVER_NL80211_TX_STATUS ]: tx status for nl80211 control port support
* [ FILS_DISCOVERY ]: FILS discovery frame transmission support
* [ UNSOL_BCAST_PROBE_RESP ]: unsolicated broadcast probe response transmission support
* [ BEACON_RATE_HE ]: HE beacon rate support (AP/mesh)
* [ BSS_COLOR ]: BSS coloring support
Redmi AX6000
root@OpenWrt-Redmi-AX6000:~# iw phy0 info
Wiphy phy0
wiphy index: 0
max # scan SSIDs: 4
max scan IEs length: 2200 bytes
max # sched scan SSIDs: 0
max # match sets: 0
Retry short limit: 7
Retry long limit: 4
Coverage class: 0 (up to 0m)
Device supports AP-side u-APSD.
Device supports T-DLS.
Available Antennas: TX 0xf RX 0xf
Configured Antennas: TX 0xf RX 0xf
Supported interface modes:
* IBSS
* managed
* AP
* AP/VLAN
* monitor
* mesh point
* P2P-client
* P2P-GO
Band 1:
Capabilities: 0x9ff
RX LDPC
HT20/HT40
SM Power Save disabled
RX Greenfield
RX HT20 SGI
RX HT40 SGI
TX STBC
RX STBC 1-stream
Max AMSDU length: 7935 bytes
No DSSS/CCK HT40
Maximum RX AMPDU length 65535 bytes (exponent: 0x003)
Minimum RX AMPDU time spacing: 4 usec (0x05)
HT TX/RX MCS rate indexes supported: 0-31
HE Iftypes: managed
HE MAC Capabilities (0x08011a000040):
+HTC HE Supported
Trigger Frame MAC Padding Duration: 2
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x2270ce126d00f3164e3f00):
HE40/2.4GHz
242 tone RUs/2.4GHz
Device Class: 1
LDPC Coding in Payload
HE SU PPDU with 1x HE-LTF and 0.8us GI
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformee
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered CQI Feedback
Partial Bandwidth Extended Range
Partial Bandwidth DL MU-MIMO
PPE Threshold Present
Power Boost Factor ar
HE SU PPDU & HE PPDU 4x HE-LTF 0.8us GI
Max NC: 2
20MHz in 40MHz HE PPDU 2.4GHz
20MHz in 160/80+80MHz HE PPDU
80MHz in 160/80+80MHz HE PPDU
DCM Max BW: 1
Longer Than 16HE SIG-B OFDM Symbols
Non-Triggered CQI Feedback
TX 1024-QAM
RX 1024-QAM
RX Full BW SU Using HE MU PPDU with Compression SIGB
RX Full BW SU Using HE MU PPDU with Non-Compression SIGB
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
PPE Threshold 0x3b 0x1c 0xc7 0x71 0x1c 0xc7 0x71 0x1c 0xc7 0x71
EHT Iftypes: managed
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: AP
HE MAC Capabilities (0x00051a081044):
+HTC HE Supported
TWT Responder
BSR
OM Control
Maximum A-MPDU Length Exponent: 3
BQR
A-MSDU in A-MPDU
OM Control UL MU Data Disable RX
HE PHY Capabilities: (0x0220ce926f1bafd0000c00):
HE40/2.4GHz
LDPC Coding in Payload
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformer
SU Beamformee
MU Beamformer
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Sounding Dimensions <= 80Mhz: 3
Sounding Dimensions > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered SU Beamforming Feedback
Triggered MU Beamforming Feedback
Partial Bandwidth Extended Range
PPE Threshold Present
Max NC: 2
STBC Tx > 80MHz
STBC Rx > 80MHz
TX 1024-QAM
RX 1024-QAM
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
PPE Threshold 0x3b 0x1c 0xc7 0x71 0x1c 0xc7 0x71 0x1c 0xc7 0x71
EHT Iftypes: AP
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: mesh point
HE MAC Capabilities (0x00011a000040):
+HTC HE Supported
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x02200c0000000000008000):
HE40/2.4GHz
LDPC Coding in Payload
STBC Tx <= 80MHz
STBC Rx <= 80MHz
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: mesh point
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw=20 MHz, max NSS for MCS 0-7: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=20 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
Frequencies:
* 2412 MHz [1] (30.0 dBm)
* 2417 MHz [2] (30.0 dBm)
* 2422 MHz [3] (30.0 dBm)
* 2427 MHz [4] (30.0 dBm)
* 2432 MHz [5] (30.0 dBm)
* 2437 MHz [6] (30.0 dBm)
* 2442 MHz [7] (30.0 dBm)
* 2447 MHz [8] (30.0 dBm)
* 2452 MHz [9] (30.0 dBm)
* 2457 MHz [10] (30.0 dBm)
* 2462 MHz [11] (30.0 dBm)
* 2467 MHz [12] (30.0 dBm)
* 2472 MHz [13] (30.0 dBm)
* 2484 MHz [14] (disabled)
valid interface combinations:
* #{ IBSS } <= 1, #{ AP, mesh point } <= 16, #{ managed } <= 19,
total <= 19, #channels <= 1, STA/AP BI must match, radar detect widths: { 20 MHz (no HT), 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz }
HT Capability overrides:
* MCS: ff ff ff ff ff ff ff ff ff ff
* maximum A-MSDU length
* supported channel width
* short GI for 40 MHz
* max A-MPDU length exponent
* min MPDU start spacing
max # scan plans: 1
max scan plan interval: -1
max scan plan iterations: 0
Supported extended features:
* [ VHT_IBSS ]: VHT-IBSS
* [ RRM ]: RRM
* [ BEACON_RATE_LEGACY ]: legacy beacon rate setting
* [ BEACON_RATE_HT ]: HT beacon rate setting
* [ BEACON_RATE_VHT ]: VHT beacon rate setting
* [ FILS_STA ]: STA FILS (Fast Initial Link Setup)
* [ CQM_RSSI_LIST ]: multiple CQM_RSSI_THOLD records
* [ CONTROL_PORT_OVER_NL80211 ]: control port over nl80211
* [ ACK_SIGNAL_SUPPORT ]: ack signal level support
* [ TXQS ]: FQ-CoDel-enabled intermediate TXQs
* [ SCAN_RANDOM_SN ]: use random sequence numbers in scans
* [ SCAN_MIN_PREQ_CONTENT ]: use probe request with only rate IEs in scans
* [ AIRTIME_FAIRNESS ]: airtime fairness scheduling
* [ STA_TX_PWR ]: TX power control per station
* [ AQL ]: Airtime Queue Limits (AQL)
* [ CONTROL_PORT_NO_PREAUTH ]: disable pre-auth over nl80211 control port support
* [ DEL_IBSS_STA ]: deletion of IBSS station support
* [ SCAN_FREQ_KHZ ]: scan on kHz frequency support
* [ CONTROL_PORT_OVER_NL80211_TX_STATUS ]: tx status for nl80211 control port support
* [ FILS_DISCOVERY ]: FILS discovery frame transmission support
* [ UNSOL_BCAST_PROBE_RESP ]: unsolicated broadcast probe response transmission support
* [ BEACON_RATE_HE ]: HE beacon rate support (AP/mesh)
* [ BSS_COLOR ]: BSS coloring support
* [ RADAR_BACKGROUND ]: Radar background support
The AX6000 is about 2/3rds the price of a BPI-R3. If you are really tight for cash, then yes, but for the extra few dollars, you do get a lot more with the R3. 2GB RAM, m.2 pcie, 2.5gbit, and 8gb emmc (plus nand and nor if you want it).
No, neither of them have 6GHz. But the BPI-R3 can add it with a card. AsiaRF is coming out with m.2 key b+m WiFi 6e card.
@jamestien that is the 2.4 ghz.
so
iw phy1 info
@VA1DER thanks
also @jamestien can you show as i said
iw phy1 info of the two devices please?
@anon4457646 Anything that can be improved?
Bananapi-BPI-R3
root@OpenWrt-Bananapi-BPI-R3:~# iw phy1 info
Wiphy phy1
wiphy index: 1
max # scan SSIDs: 4
max scan IEs length: 2190 bytes
max # sched scan SSIDs: 0
max # match sets: 0
Retry short limit: 7
Retry long limit: 4
Coverage class: 0 (up to 0m)
Device supports AP-side u-APSD.
Device supports T-DLS.
Available Antennas: TX 0xf RX 0xf
Configured Antennas: TX 0xf RX 0xf
Supported interface modes:
* IBSS
* managed
* AP
* AP/VLAN
* monitor
* mesh point
* P2P-client
* P2P-GO
Band 2:
Capabilities: 0x9ff
RX LDPC
HT20/HT40
SM Power Save disabled
RX Greenfield
RX HT20 SGI
RX HT40 SGI
TX STBC
RX STBC 1-stream
Max AMSDU length: 7935 bytes
No DSSS/CCK HT40
Maximum RX AMPDU length 65535 bytes (exponent: 0x003)
Minimum RX AMPDU time spacing: 4 usec (0x05)
HT TX/RX MCS rate indexes supported: 0-31
VHT Capabilities (0x339b79f6):
Max MPDU length: 11454
Supported Channel Width: 160 MHz
RX LDPC
short GI (80 MHz)
short GI (160/80+80 MHz)
TX STBC
SU Beamformer
SU Beamformee
MU Beamformer
MU Beamformee
RX antenna pattern consistency
TX antenna pattern consistency
VHT RX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: MCS 0-9
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT RX highest supported: 0 Mbps
VHT TX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: MCS 0-9
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT TX highest supported: 0 Mbps
VHT extended NSS: supported
HE Iftypes: managed
HE MAC Capabilities (0x08011a000040):
+HTC HE Supported
Trigger Frame MAC Padding Duration: 2
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x5c70ce126d00f3164e3f00):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
242 tone RUs/5GHz
Device Class: 1
LDPC Coding in Payload
HE SU PPDU with 1x HE-LTF and 0.8us GI
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformee
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered CQI Feedback
Partial Bandwidth Extended Range
Partial Bandwidth DL MU-MIMO
PPE Threshold Present
Power Boost Factor ar
HE SU PPDU & HE PPDU 4x HE-LTF 0.8us GI
Max NC: 2
20MHz in 40MHz HE PPDU 2.4GHz
20MHz in 160/80+80MHz HE PPDU
80MHz in 160/80+80MHz HE PPDU
DCM Max BW: 1
Longer Than 16HE SIG-B OFDM Symbols
Non-Triggered CQI Feedback
TX 1024-QAM
RX 1024-QAM
RX Full BW SU Using HE MU PPDU with Compression SIGB
RX Full BW SU Using HE MU PPDU with Non-Compression SIGB
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: managed
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: AP
HE MAC Capabilities (0x00051a081044):
+HTC HE Supported
TWT Responder
BSR
OM Control
Maximum A-MPDU Length Exponent: 3
BQR
A-MSDU in A-MPDU
OM Control UL MU Data Disable RX
HE PHY Capabilities: (0x1c20ce926f1bafd0000c00):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
LDPC Coding in Payload
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformer
SU Beamformee
MU Beamformer
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Sounding Dimensions <= 80Mhz: 3
Sounding Dimensions > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered SU Beamforming Feedback
Triggered MU Beamforming Feedback
Partial Bandwidth Extended Range
PPE Threshold Present
Max NC: 2
STBC Tx > 80MHz
STBC Rx > 80MHz
TX 1024-QAM
RX 1024-QAM
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: AP
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: mesh point
HE MAC Capabilities (0x00011a000040):
+HTC HE Supported
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x1c200c0000000000008000):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
LDPC Coding in Payload
STBC Tx <= 80MHz
STBC Rx <= 80MHz
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: mesh point
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
Frequencies:
* 5180 MHz [36] (20.0 dBm)
* 5200 MHz [40] (20.0 dBm)
* 5220 MHz [44] (20.0 dBm)
* 5240 MHz [48] (20.0 dBm)
* 5260 MHz [52] (20.0 dBm) (no IR, radar detection)
* 5280 MHz [56] (20.0 dBm) (no IR, radar detection)
* 5300 MHz [60] (20.0 dBm) (no IR, radar detection)
* 5320 MHz [64] (20.0 dBm) (no IR, radar detection)
* 5500 MHz [100] (20.0 dBm) (no IR, radar detection)
* 5520 MHz [104] (20.0 dBm) (no IR, radar detection)
* 5540 MHz [108] (20.0 dBm) (no IR, radar detection)
* 5560 MHz [112] (20.0 dBm) (no IR, radar detection)
* 5580 MHz [116] (20.0 dBm) (no IR, radar detection)
* 5600 MHz [120] (20.0 dBm) (no IR, radar detection)
* 5620 MHz [124] (20.0 dBm) (no IR, radar detection)
* 5640 MHz [128] (20.0 dBm) (no IR, radar detection)
* 5660 MHz [132] (20.0 dBm) (no IR, radar detection)
* 5680 MHz [136] (20.0 dBm) (no IR, radar detection)
* 5700 MHz [140] (20.0 dBm) (no IR, radar detection)
* 5720 MHz [144] (20.0 dBm) (no IR, radar detection)
* 5745 MHz [149] (20.0 dBm) (no IR)
* 5765 MHz [153] (20.0 dBm) (no IR)
* 5785 MHz [157] (20.0 dBm) (no IR)
* 5805 MHz [161] (20.0 dBm) (no IR)
* 5825 MHz [165] (20.0 dBm) (no IR)
* 5845 MHz [169] (disabled)
* 5865 MHz [173] (disabled)
valid interface combinations:
* #{ IBSS } <= 1, #{ AP, mesh point } <= 16, #{ managed } <= 19,
total <= 19, #channels <= 1, STA/AP BI must match, radar detect widths: { 20 MHz (no HT), 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz }
HT Capability overrides:
* MCS: ff ff ff ff ff ff ff ff ff ff
* maximum A-MSDU length
* supported channel width
* short GI for 40 MHz
* max A-MPDU length exponent
* min MPDU start spacing
max # scan plans: 1
max scan plan interval: -1
max scan plan iterations: 0
Supported extended features:
* [ VHT_IBSS ]: VHT-IBSS
* [ RRM ]: RRM
* [ BEACON_RATE_LEGACY ]: legacy beacon rate setting
* [ BEACON_RATE_HT ]: HT beacon rate setting
* [ BEACON_RATE_VHT ]: VHT beacon rate setting
* [ FILS_STA ]: STA FILS (Fast Initial Link Setup)
* [ CQM_RSSI_LIST ]: multiple CQM_RSSI_THOLD records
* [ CONTROL_PORT_OVER_NL80211 ]: control port over nl80211
* [ ACK_SIGNAL_SUPPORT ]: ack signal level support
* [ TXQS ]: FQ-CoDel-enabled intermediate TXQs
* [ SCAN_RANDOM_SN ]: use random sequence numbers in scans
* [ SCAN_MIN_PREQ_CONTENT ]: use probe request with only rate IEs in scans
* [ AIRTIME_FAIRNESS ]: airtime fairness scheduling
* [ AQL ]: Airtime Queue Limits (AQL)
* [ CONTROL_PORT_NO_PREAUTH ]: disable pre-auth over nl80211 control port support
* [ DEL_IBSS_STA ]: deletion of IBSS station support
* [ SCAN_FREQ_KHZ ]: scan on kHz frequency support
* [ CONTROL_PORT_OVER_NL80211_TX_STATUS ]: tx status for nl80211 control port support
* [ FILS_DISCOVERY ]: FILS discovery frame transmission support
* [ UNSOL_BCAST_PROBE_RESP ]: unsolicated broadcast probe response transmission support
* [ BEACON_RATE_HE ]: HE beacon rate support (AP/mesh)
* [ BSS_COLOR ]: BSS coloring support
Redmi AX6000
root@OpenWrt-Redmi-AX6000:~# iw phy1 info
Wiphy phy1
wiphy index: 1
max # scan SSIDs: 4
max scan IEs length: 2190 bytes
max # sched scan SSIDs: 0
max # match sets: 0
Retry short limit: 7
Retry long limit: 4
Coverage class: 0 (up to 0m)
Device supports AP-side u-APSD.
Device supports T-DLS.
Available Antennas: TX 0xf RX 0xf
Configured Antennas: TX 0xf RX 0xf
Supported interface modes:
* IBSS
* managed
* AP
* AP/VLAN
* monitor
* mesh point
* P2P-client
* P2P-GO
Band 2:
Capabilities: 0x9ff
RX LDPC
HT20/HT40
SM Power Save disabled
RX Greenfield
RX HT20 SGI
RX HT40 SGI
TX STBC
RX STBC 1-stream
Max AMSDU length: 7935 bytes
No DSSS/CCK HT40
Maximum RX AMPDU length 65535 bytes (exponent: 0x003)
Minimum RX AMPDU time spacing: 4 usec (0x05)
HT TX/RX MCS rate indexes supported: 0-31
VHT Capabilities (0x339b79f6):
Max MPDU length: 11454
Supported Channel Width: 160 MHz
RX LDPC
short GI (80 MHz)
short GI (160/80+80 MHz)
TX STBC
SU Beamformer
SU Beamformee
MU Beamformer
MU Beamformee
RX antenna pattern consistency
TX antenna pattern consistency
VHT RX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: MCS 0-9
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT RX highest supported: 0 Mbps
VHT TX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: MCS 0-9
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT TX highest supported: 0 Mbps
VHT extended NSS: supported
HE Iftypes: managed
HE MAC Capabilities (0x08011a000040):
+HTC HE Supported
Trigger Frame MAC Padding Duration: 2
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x5c70ce126d00f3164e3f00):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
242 tone RUs/5GHz
Device Class: 1
LDPC Coding in Payload
HE SU PPDU with 1x HE-LTF and 0.8us GI
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformee
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered CQI Feedback
Partial Bandwidth Extended Range
Partial Bandwidth DL MU-MIMO
PPE Threshold Present
Power Boost Factor ar
HE SU PPDU & HE PPDU 4x HE-LTF 0.8us GI
Max NC: 2
20MHz in 40MHz HE PPDU 2.4GHz
20MHz in 160/80+80MHz HE PPDU
80MHz in 160/80+80MHz HE PPDU
DCM Max BW: 1
Longer Than 16HE SIG-B OFDM Symbols
Non-Triggered CQI Feedback
TX 1024-QAM
RX 1024-QAM
RX Full BW SU Using HE MU PPDU with Compression SIGB
RX Full BW SU Using HE MU PPDU with Non-Compression SIGB
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: managed
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: AP
HE MAC Capabilities (0x00051a081044):
+HTC HE Supported
TWT Responder
BSR
OM Control
Maximum A-MPDU Length Exponent: 3
BQR
A-MSDU in A-MPDU
OM Control UL MU Data Disable RX
HE PHY Capabilities: (0x1c20ce926f1bafd0000c00):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
LDPC Coding in Payload
NDP with 4x HE-LTF and 3.2us GI
STBC Tx <= 80MHz
STBC Rx <= 80MHz
Full Bandwidth UL MU-MIMO
Partial Bandwidth UL MU-MIMO
DCM Max Constellation: 2
DCM Max Constellation Rx: 2
SU Beamformer
SU Beamformee
MU Beamformer
Beamformee STS <= 80Mhz: 3
Beamformee STS > 80Mhz: 3
Sounding Dimensions <= 80Mhz: 3
Sounding Dimensions > 80Mhz: 3
Codebook Size SU Feedback
Codebook Size MU Feedback
Triggered SU Beamforming Feedback
Triggered MU Beamforming Feedback
Partial Bandwidth Extended Range
PPE Threshold Present
Max NC: 2
STBC Tx > 80MHz
STBC Rx > 80MHz
TX 1024-QAM
RX 1024-QAM
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: AP
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
HE Iftypes: mesh point
HE MAC Capabilities (0x00011a000040):
+HTC HE Supported
OM Control
Maximum A-MPDU Length Exponent: 3
A-MSDU in A-MPDU
HE PHY Capabilities: (0x1c200c0000000000008000):
HE40/HE80/5GHz
HE160/5GHz
HE160/HE80+80/5GHz
LDPC Coding in Payload
STBC Tx <= 80MHz
STBC Rx <= 80MHz
HE RX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set <= 80 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE RX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
HE TX MCS and NSS set 160 MHz
1 streams: MCS 0-11
2 streams: MCS 0-11
3 streams: MCS 0-11
4 streams: MCS 0-11
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
EHT Iftypes: mesh point
EHT MAC Capabilities (0x0000):
EHT PHY Capabilities: (0x0000000000000000):
EHT MCS/NSS: (0x):
EHT bw <= 80 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw <= 80 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 8-9: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 10-11: Rx=0, Tx=0
EHT bw=160 MHz, max NSS for MCS 12-13: Rx=0, Tx=0
Frequencies:
* 5180 MHz [36] (30.0 dBm)
* 5200 MHz [40] (30.0 dBm)
* 5220 MHz [44] (30.0 dBm)
* 5240 MHz [48] (30.0 dBm)
* 5260 MHz [52] (30.0 dBm)
* 5280 MHz [56] (30.0 dBm)
* 5300 MHz [60] (30.0 dBm)
* 5320 MHz [64] (30.0 dBm)
* 5500 MHz [100] (30.0 dBm)
* 5520 MHz [104] (30.0 dBm)
* 5540 MHz [108] (30.0 dBm)
* 5560 MHz [112] (30.0 dBm)
* 5580 MHz [116] (30.0 dBm)
* 5600 MHz [120] (30.0 dBm)
* 5620 MHz [124] (30.0 dBm)
* 5640 MHz [128] (30.0 dBm)
* 5660 MHz [132] (30.0 dBm)
* 5680 MHz [136] (30.0 dBm)
* 5700 MHz [140] (30.0 dBm)
* 5720 MHz [144] (30.0 dBm)
* 5745 MHz [149] (30.0 dBm)
* 5765 MHz [153] (30.0 dBm)
* 5785 MHz [157] (30.0 dBm)
* 5805 MHz [161] (30.0 dBm)
* 5825 MHz [165] (30.0 dBm)
* 5845 MHz [169] (disabled)
* 5865 MHz [173] (disabled)
valid interface combinations:
* #{ IBSS } <= 1, #{ AP, mesh point } <= 16, #{ managed } <= 19,
total <= 19, #channels <= 1, STA/AP BI must match, radar detect widths: { 20 MHz (no HT), 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz }
HT Capability overrides:
* MCS: ff ff ff ff ff ff ff ff ff ff
* maximum A-MSDU length
* supported channel width
* short GI for 40 MHz
* max A-MPDU length exponent
* min MPDU start spacing
max # scan plans: 1
max scan plan interval: -1
max scan plan iterations: 0
Supported extended features:
* [ VHT_IBSS ]: VHT-IBSS
* [ RRM ]: RRM
* [ BEACON_RATE_LEGACY ]: legacy beacon rate setting
* [ BEACON_RATE_HT ]: HT beacon rate setting
* [ BEACON_RATE_VHT ]: VHT beacon rate setting
* [ FILS_STA ]: STA FILS (Fast Initial Link Setup)
* [ CQM_RSSI_LIST ]: multiple CQM_RSSI_THOLD records
* [ CONTROL_PORT_OVER_NL80211 ]: control port over nl80211
* [ ACK_SIGNAL_SUPPORT ]: ack signal level support
* [ TXQS ]: FQ-CoDel-enabled intermediate TXQs
* [ SCAN_RANDOM_SN ]: use random sequence numbers in scans
* [ SCAN_MIN_PREQ_CONTENT ]: use probe request with only rate IEs in scans
* [ AIRTIME_FAIRNESS ]: airtime fairness scheduling
* [ STA_TX_PWR ]: TX power control per station
* [ AQL ]: Airtime Queue Limits (AQL)
* [ CONTROL_PORT_NO_PREAUTH ]: disable pre-auth over nl80211 control port support
* [ DEL_IBSS_STA ]: deletion of IBSS station support
* [ SCAN_FREQ_KHZ ]: scan on kHz frequency support
* [ CONTROL_PORT_OVER_NL80211_TX_STATUS ]: tx status for nl80211 control port support
* [ FILS_DISCOVERY ]: FILS discovery frame transmission support
* [ UNSOL_BCAST_PROBE_RESP ]: unsolicated broadcast probe response transmission support
* [ BEACON_RATE_HE ]: HE beacon rate support (AP/mesh)
* [ BSS_COLOR ]: BSS coloring support
* [ RADAR_BACKGROUND ]: Radar background support
that's strange do you have same country code on the two device? the redmi ax 6000 seems have no rules in reg.db
I use driver default on both device.
The strange thing is, when I connect my iPad Air 2 to Redmi AX6000 (AX) I can only get about 120Mbps, no matter how close it is to AX6000.
iperf3 (iPad Air 2 to LAN)
-----------------------------------------------------------
Server listening on 5201 (test #1)
-----------------------------------------------------------
Accepted connection from 192.168.0.161, port 49158
[ 5] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49159
[ 8] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49160
[ 10] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49161
[ 12] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49162
[ 14] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49163
[ ID] Interval Transfer Bitrate Retr Cwnd
[ 5] 0.00-1.00 sec 778 KBytes 6.37 Mbits/sec 91 38.2 KBytes
[ 8] 0.00-1.00 sec 1.22 MBytes 10.2 Mbits/sec 110 56.6 KBytes
[ 10] 0.00-1.00 sec 2.49 MBytes 20.9 Mbits/sec 70 1.41 KBytes
[ 12] 0.00-1.00 sec 905 KBytes 7.41 Mbits/sec 102 32.5 KBytes
[ 14] 0.00-1.00 sec 1.82 MBytes 15.2 Mbits/sec 150 1.41 KBytes
[SUM] 0.00-1.00 sec 7.17 MBytes 60.1 Mbits/sec 523
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 1.00-2.00 sec 10.3 MBytes 86.5 Mbits/sec 12 129 KBytes
[ 8] 1.00-2.00 sec 11.1 MBytes 92.8 Mbits/sec 24 136 KBytes
[ 10] 1.00-2.00 sec 5.53 MBytes 46.4 Mbits/sec 22 94.7 KBytes
[ 12] 1.00-2.00 sec 17.0 MBytes 143 Mbits/sec 24 731 KBytes
[ 14] 1.00-2.00 sec 2.80 MBytes 23.5 Mbits/sec 22 147 KBytes
[SUM] 1.00-2.00 sec 46.7 MBytes 392 Mbits/sec 104
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 2.00-3.00 sec 3.60 MBytes 30.2 Mbits/sec 1 107 KBytes
[ 8] 2.00-3.00 sec 3.98 MBytes 33.4 Mbits/sec 0 156 KBytes
[ 10] 2.00-3.00 sec 2.86 MBytes 24.0 Mbits/sec 0 116 KBytes
[ 12] 2.00-3.00 sec 21.2 MBytes 178 Mbits/sec 3 1.03 MBytes
[ 14] 2.00-3.00 sec 8.02 MBytes 67.2 Mbits/sec 1 427 KBytes
[SUM] 2.00-3.00 sec 39.7 MBytes 333 Mbits/sec 5
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 3.00-4.00 sec 1.24 MBytes 10.4 Mbits/sec 20 63.6 KBytes
[ 8] 3.00-4.00 sec 1.43 MBytes 12.0 Mbits/sec 22 76.4 KBytes
[ 10] 3.00-4.00 sec 1.12 MBytes 9.38 Mbits/sec 22 60.8 KBytes
[ 12] 3.00-4.00 sec 7.50 MBytes 62.9 Mbits/sec 41 404 KBytes
[ 14] 3.00-4.00 sec 4.23 MBytes 35.4 Mbits/sec 38 175 KBytes
[SUM] 3.00-4.00 sec 15.5 MBytes 130 Mbits/sec 143
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 4.00-5.00 sec 1.55 MBytes 13.0 Mbits/sec 0 80.6 KBytes
[ 8] 4.00-5.00 sec 1.93 MBytes 16.2 Mbits/sec 0 94.7 KBytes
[ 10] 4.00-5.00 sec 1.74 MBytes 14.6 Mbits/sec 0 79.2 KBytes
[ 12] 4.00-5.00 sec 6.25 MBytes 52.4 Mbits/sec 0 436 KBytes
[ 14] 4.00-5.00 sec 2.98 MBytes 25.0 Mbits/sec 0 191 KBytes
[SUM] 4.00-5.00 sec 14.5 MBytes 121 Mbits/sec 0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 5.00-6.00 sec 2.17 MBytes 18.2 Mbits/sec 0 97.6 KBytes
[ 8] 5.00-6.00 sec 2.42 MBytes 20.3 Mbits/sec 0 112 KBytes
[ 10] 5.00-6.00 sec 1.99 MBytes 16.7 Mbits/sec 0 96.2 KBytes
[ 12] 5.00-6.00 sec 5.00 MBytes 41.9 Mbits/sec 1 334 KBytes
[ 14] 5.00-6.00 sec 4.04 MBytes 33.9 Mbits/sec 0 202 KBytes
[SUM] 5.00-6.00 sec 15.6 MBytes 131 Mbits/sec 1
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 6.00-7.00 sec 2.17 MBytes 18.2 Mbits/sec 0 115 KBytes
[ 8] 6.00-7.00 sec 2.49 MBytes 20.9 Mbits/sec 0 127 KBytes
[ 10] 6.00-7.00 sec 1.99 MBytes 16.7 Mbits/sec 0 113 KBytes
[ 12] 6.00-7.00 sec 5.00 MBytes 41.9 Mbits/sec 1 252 KBytes
[ 14] 6.00-7.00 sec 3.98 MBytes 33.4 Mbits/sec 0 218 KBytes
[SUM] 6.00-7.00 sec 15.6 MBytes 131 Mbits/sec 1
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 7.00-8.00 sec 2.49 MBytes 20.9 Mbits/sec 0 130 KBytes
[ 8] 7.00-8.00 sec 2.67 MBytes 22.4 Mbits/sec 0 143 KBytes
[ 10] 7.00-8.00 sec 2.67 MBytes 22.4 Mbits/sec 0 129 KBytes
[ 12] 7.00-8.00 sec 3.75 MBytes 31.5 Mbits/sec 1 195 KBytes
[ 14] 7.00-8.00 sec 3.98 MBytes 33.4 Mbits/sec 0 230 KBytes
[SUM] 7.00-8.00 sec 15.6 MBytes 131 Mbits/sec 1
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 8.00-9.00 sec 2.80 MBytes 23.5 Mbits/sec 0 146 KBytes
[ 8] 8.00-9.00 sec 2.73 MBytes 22.9 Mbits/sec 0 158 KBytes
[ 10] 8.00-9.00 sec 2.80 MBytes 23.5 Mbits/sec 0 144 KBytes
[ 12] 8.00-9.00 sec 3.75 MBytes 31.5 Mbits/sec 0 215 KBytes
[ 14] 8.00-9.00 sec 4.23 MBytes 35.4 Mbits/sec 1 170 KBytes
[SUM] 8.00-9.00 sec 16.3 MBytes 137 Mbits/sec 1
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 9.00-10.00 sec 2.92 MBytes 24.5 Mbits/sec 0 161 KBytes
[ 8] 9.00-10.00 sec 3.36 MBytes 28.1 Mbits/sec 0 173 KBytes
[ 10] 9.00-10.00 sec 3.04 MBytes 25.5 Mbits/sec 0 160 KBytes
[ 12] 9.00-10.00 sec 3.75 MBytes 31.5 Mbits/sec 0 223 KBytes
[ 14] 9.00-10.00 sec 2.98 MBytes 25.0 Mbits/sec 0 204 KBytes
[SUM] 9.00-10.00 sec 16.1 MBytes 135 Mbits/sec 0
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bitrate Retr
[ 5] 0.00-10.02 sec 30.0 MBytes 25.1 Mbits/sec 124 sender
[ 8] 0.00-10.02 sec 33.3 MBytes 27.9 Mbits/sec 156 sender
[ 10] 0.00-10.02 sec 26.2 MBytes 22.0 Mbits/sec 114 sender
[ 12] 0.00-10.02 sec 74.1 MBytes 62.0 Mbits/sec 173 sender
[ 14] 0.00-10.02 sec 39.0 MBytes 32.7 Mbits/sec 212 sender
[SUM] 0.00-10.02 sec 203 MBytes 170 Mbits/sec 779 sender
-----------------------------------------------------------
Server listening on 5201 (test #2)
-----------------------------------------------------------
Accepted connection from 192.168.0.161, port 49164
[ 5] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49165
[ 8] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49166
[ 10] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49167
[ 12] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49168
[ 14] local 192.168.0.200 port 5201 connected to 192.168.0.161 port 49169
[ ID] Interval Transfer Bitrate
[ 5] 0.00-1.00 sec 9.83 MBytes 82.5 Mbits/sec
[ 8] 0.00-1.00 sec 9.79 MBytes 82.1 Mbits/sec
[ 10] 0.00-1.00 sec 9.83 MBytes 82.5 Mbits/sec
[ 12] 0.00-1.00 sec 9.82 MBytes 82.4 Mbits/sec
[ 14] 0.00-1.00 sec 9.91 MBytes 83.1 Mbits/sec
[SUM] 0.00-1.00 sec 49.2 MBytes 413 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 1.00-2.00 sec 10.9 MBytes 91.5 Mbits/sec
[ 8] 1.00-2.00 sec 10.9 MBytes 91.8 Mbits/sec
[ 10] 1.00-2.00 sec 10.9 MBytes 91.3 Mbits/sec
[ 12] 1.00-2.00 sec 10.9 MBytes 91.7 Mbits/sec
[ 14] 1.00-2.00 sec 10.9 MBytes 91.1 Mbits/sec
[SUM] 1.00-2.00 sec 54.5 MBytes 457 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 2.00-3.00 sec 10.9 MBytes 91.7 Mbits/sec
[ 8] 2.00-3.00 sec 10.9 MBytes 91.6 Mbits/sec
[ 10] 2.00-3.00 sec 11.0 MBytes 92.5 Mbits/sec
[ 12] 2.00-3.00 sec 11.0 MBytes 92.1 Mbits/sec
[ 14] 2.00-3.00 sec 11.1 MBytes 93.1 Mbits/sec
[SUM] 2.00-3.00 sec 54.9 MBytes 461 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 3.00-4.00 sec 10.9 MBytes 91.6 Mbits/sec
[ 8] 3.00-4.00 sec 10.9 MBytes 91.1 Mbits/sec
[ 10] 3.00-4.00 sec 10.9 MBytes 91.7 Mbits/sec
[ 12] 3.00-4.00 sec 10.8 MBytes 91.0 Mbits/sec
[ 14] 3.00-4.00 sec 10.9 MBytes 91.1 Mbits/sec
[SUM] 3.00-4.00 sec 54.4 MBytes 456 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 4.00-5.00 sec 11.0 MBytes 92.4 Mbits/sec
[ 8] 4.00-5.00 sec 11.0 MBytes 92.1 Mbits/sec
[ 10] 4.00-5.00 sec 11.0 MBytes 92.0 Mbits/sec
[ 12] 4.00-5.00 sec 11.0 MBytes 92.0 Mbits/sec
[ 14] 4.00-5.00 sec 11.0 MBytes 92.3 Mbits/sec
[SUM] 4.00-5.00 sec 54.9 MBytes 461 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 5.00-6.00 sec 11.0 MBytes 92.0 Mbits/sec
[ 8] 5.00-6.00 sec 11.0 MBytes 92.0 Mbits/sec
[ 10] 5.00-6.00 sec 11.0 MBytes 92.3 Mbits/sec
[ 12] 5.00-6.00 sec 11.0 MBytes 92.2 Mbits/sec
[ 14] 5.00-6.00 sec 10.9 MBytes 91.8 Mbits/sec
[SUM] 5.00-6.00 sec 54.9 MBytes 460 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 6.00-7.00 sec 10.9 MBytes 91.3 Mbits/sec
[ 8] 6.00-7.00 sec 10.9 MBytes 91.1 Mbits/sec
[ 10] 6.00-7.00 sec 11.0 MBytes 92.4 Mbits/sec
[ 12] 6.00-7.00 sec 10.9 MBytes 91.4 Mbits/sec
[ 14] 6.00-7.00 sec 11.0 MBytes 92.7 Mbits/sec
[SUM] 6.00-7.00 sec 54.7 MBytes 459 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 7.00-8.00 sec 11.0 MBytes 92.5 Mbits/sec
[ 8] 7.00-8.00 sec 11.0 MBytes 92.5 Mbits/sec
[ 10] 7.00-8.00 sec 11.1 MBytes 92.8 Mbits/sec
[ 12] 7.00-8.00 sec 10.9 MBytes 91.5 Mbits/sec
[ 14] 7.00-8.00 sec 10.9 MBytes 91.8 Mbits/sec
[SUM] 7.00-8.00 sec 55.0 MBytes 461 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 8.00-9.00 sec 11.0 MBytes 92.1 Mbits/sec
[ 8] 8.00-9.00 sec 11.0 MBytes 92.1 Mbits/sec
[ 10] 8.00-9.00 sec 11.0 MBytes 92.1 Mbits/sec
[ 12] 8.00-9.00 sec 10.9 MBytes 91.6 Mbits/sec
[ 14] 8.00-9.00 sec 11.0 MBytes 92.2 Mbits/sec
[SUM] 8.00-9.00 sec 54.8 MBytes 460 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 9.00-10.00 sec 11.0 MBytes 92.0 Mbits/sec
[ 8] 9.00-10.00 sec 10.9 MBytes 91.8 Mbits/sec
[ 10] 9.00-10.00 sec 10.9 MBytes 91.8 Mbits/sec
[ 12] 9.00-10.00 sec 11.0 MBytes 92.5 Mbits/sec
[ 14] 9.00-10.00 sec 11.0 MBytes 91.9 Mbits/sec
[SUM] 9.00-10.00 sec 54.8 MBytes 460 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ 5] 10.00-10.01 sec 93.3 KBytes 84.8 Mbits/sec
[ 8] 10.00-10.01 sec 113 KBytes 103 Mbits/sec
[ 10] 10.00-10.01 sec 76.4 KBytes 69.4 Mbits/sec
[ 12] 10.00-10.01 sec 82.0 KBytes 74.6 Mbits/sec
[ 14] 10.00-10.01 sec 76.4 KBytes 69.4 Mbits/sec
[SUM] 10.00-10.01 sec 441 KBytes 401 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bitrate
[ 5] 0.00-10.01 sec 109 MBytes 91.0 Mbits/sec receiver
[ 8] 0.00-10.01 sec 108 MBytes 90.8 Mbits/sec receiver
[ 10] 0.00-10.01 sec 109 MBytes 91.1 Mbits/sec receiver
[ 12] 0.00-10.01 sec 108 MBytes 90.8 Mbits/sec receiver
[ 14] 0.00-10.01 sec 109 MBytes 91.1 Mbits/sec receiver
[SUM] 0.00-10.01 sec 543 MBytes 455 Mbits/sec receiver
we are going off topic here,anyway try to set txpower from 30 dbm to 20 dbm, on redmi. also check on both devices
iw reg get
**Check this in your wifi settings**
Try to set the DTIM interval to 3, always use powers lower than the maximum power, especially if you are always using your Ipad or wireless devices near the router, because a high or very low power makes that the modulation that can be achieved in the wireless link is not the highest, try not to use any DFS channels, these are very problematic, do not use channel widths higher than 80 MHz in the 5GHz band, make sure you have the short preamble box checked and WMM mode, try using WPA2-PSK encryption if you are using a mixed mode with WPA3 or just WPA3.
I wanted to ask in which country you live and how long it took to get the Banana Pi R3, in pictures it looks very good option, it has SFP port, but I live in a country where Movistar is used, I have no experience with these devices and I do not know which module could serve to connect the fiber directly into the Banana Pi R3.
Thank you, I use default when I don't know which is the best option.
I live in Philippines, I opted for FEdex shipping which only took 3 days (exclude local shipping, from seller to FEdex collection center) from China.
I have the same problem transfering image to EMMC. I tried official Openwrt or the one I built myself. Non worked. But no problem with SD card or Nand.
Care to share how to copy SD image to every other storage?
I used 7,8, 5 in this order. But when I reboot it, it just shows "mt7896" and does not go further. Not sure what I missed.
You can try to use "Install bootloader, recover, production to xxx" procedure as show in the picture I posted.
Prepare SD image
#wipe SD card include magic string, change # to actual letter
sudo wipefs -a /dev/sd#
#copy image to SD card.
sudo bpi-copy openwrt-mediatek-filogic-bananapi_bpi-r3-sdcard.img /dev/sd#
- switch to SD and power on, do "install,recovery, production to NAND".
- switch to NAND and power on, do "install,recovery, production to eMMC".
- switch to eMMC and boot normally.
Thanks much!
I did all the steps but did not stop. After switching to eMMC, I continued to do 7, 8, and 5. That's why it failed. everything is good now.
I just placed an order for banana pi r3 with case. Didn’t like their antennas and psu and will need to get them myself.
How long is the original antenna cable (u.fl to ro-sma)?
Device is 15cm from one side to another so would 15cm antenna fit nicely? Or would i better pick 20cm and do some cable management?
Does SQM still not work? BPI-R3 seems like nearly the perfect device. The one thing I haven't been able to confirm is what speed it can sustain with (working) SQM.
the SinoVoip kits come with 8 x 20cm 1.1mm cables
15cm would be a little tight for the opposite side. I don't have any 15cm cables, but you'd have almost nothing to spare and no way to route around some chips.
I am using RG178 cables, 5cm for the antennae on one side, and 20cm for the other. This is letting me keep the cables fairly well clear of the SoC.
EDIT: It just dawned on me that the post I just responded two was three months ago.
